MX3500N SIMULATION 7 – 83
ORG RECOG 4 digits or
less setting
A MVSTRSEL REDUCE Text pixel judgment result
select register (for reduction)
0 – 2 0 A
B MVSTRSEL ENLARGE Text pixel judgment result
select register (for
enlargement)
0 – 2 0
C PSEL1 REDUCE Photographic paper judgment
table select register for each
signal (for reduction)
0 – 1 0
D PSEL1 ENLARGE Photographic paper judgment
table select register for each
signal (for enlargement)
0 – 1 0
E PSEL2 REDUCE Photographic paper pixel final
judgment table select register
(for reduction)
0 – 2 0
F PSEL2 ENLARGE Photographic paper pixel final
judgment table select register
(for enlargement)
0 – 2 0
G BUSYSEL REDUCE Frequency comparison value
select register (for reduction)
0 – 1 1
H BUSYSEL ENLARGE Frequency comparison value
select register (for
enlargement)
0 – 1 1
I HTSEL REDUCE AREA Mesh
judgment
result select
(for reduction)
Area
separation
mesh
judgment
result
0 –
1
01
ORG Document
discrimination
mesh
judgment
result
1
J HTSEL ENLARGE AREA Mesh
judgment
result select
(for
enlargement)
Area
separation
mesh
judgment
result
0 –
1
01
ORG Document
discrimination
mesh
judgment
result
1
K ASEL REDUCE Integrated judgment priority
select register (for reduction)
0 – 23 16
L ASEL ENLARGE Integrated judgment priority
select register (for
enlargement)
0 – 23 16
M HSTSEL REDUCE Histogram division fluctuation
register (for reduction)
0 – 3 0
N HSTSEL ENLARGE Histogram division fluctuation
register (for enlargement)
0 – 3 0
O HSTSEL2 REDUCE Max. density difference
histogram division fluctuation
register (for reduction)
0 – 3 3
P HSTSEL2 ENLARGE Max. density difference
histogram division fluctuation
register (for enlargement)
0 – 3 3
Q TH_SUM_BETARGB Threshold value of all divisions
of background high level
number (for base)
0 – 32 6
R TH_BETA_SUB Monochrome base judgment
threshold value
0 – 32 5
S TH_WHITE_BETA White base judgment threshold
value
0 – 32 25
T TH_GRAY_BETA1 Gray base judgment threshold
value 1
0 – 32
18
U TH_GRAY_BETA2 Gray base judgment threshold
value 2
0 – 32 25
V TH_NOISE REDUCE Mesh noise threshold value (for
reduction)
0 – 32 10
W TH_NOISE ENLARGE Mesh noise threshold value (for
enlargement)
0 – 32 10
X SW_SCR1 Mesh ratio judgment switch 0 – 1 0
Y SW_SCR2 Mesh judgment switch 0 – 1 0
Category Item
Display Content Set range/Number of digits
Default
value
Screen
type
