MX3500N SIMULATION 7 – 106
<Error displays and contents in error end>
Error
code
Error display Error content Detail of content
Compulsory
end error
- SUSPENDED Door open end Door open during operation
- SUSPENDED CA end Pressing [CA] button during operation
- - OFF end Unconfirmed operation (power OFF) during operation
Basic error 1 TONER EMPTY Toner empty BK or all colors toner empty detection
2TONER BEFORE
BEHAVIOR
Other conditions Other conditions
4 SENSOR CALIBRATION Calibration error With 3 times of retry of F or R, the target is not reached.
5 TIME OVER Time error Data is not acquired for 90sec from data acquisition
7 PROCESS CONTROL Process control error Process control error detection
Sub scan
adjustment
error
10 MAIN BLACK FRONT Number error sub scan BLACK F The number of pitch data is not the specified number.
11 MAIN BLACK FRONT Pitch error sub scan BLACK F The pitch data is not in the specified allowable range.
15 SUB BLACK REAR Number error sub scan BLACK R The number of pitch data is not in the specified range.
16 SUB BLACK REAR Pitch error sub scan BLACK R The pitch data is not in the specified allowable range.
20 SUB CYAN FRONT Number error sub scan CYAN F The number of pitch data is not the specified number.
21 SUB CYAN FRONT Pitch error sub scan CYAN F The pitch data is not in the specified allowable range.
22 SUB CYAN FRONT Adjustment value error sub scan
CYAN F
The calculation result value is not in the specified allowable
range.
23 SUB CYAN FRONT Result value error sub scan CYAN F The variation of the calculation result value is over the
specified allowable range.
25 SUB CYAN REAR Number error sub scan CYAN R The number of pitch data is not the specified number.
26 SUB CYAN REAR Pitch error sub scan CYAN R The pitch data is not in the specified allowable range.
27 SUB CYAN REAR Adjustment value error sub scan
CYAN R
The calculation result value is not in the specified allowable
range.
28 SUB CYAN REAR Result value error sub scan CYAN
R
The variation of the calculation result value is over the
specified allowable range.
30 SUB MAGENTA FRONT Number error sub scan MAGENTA
F
The number of pitch data is not the specified number.
31 SUB MAGENTA FRONT Pitch error sub scan MAGENTA F The pitch data is not in the specified allowable range.
32 SUB MAGENTA FRONT Adjustment value error sub scan
MAGENTA F
The calculation result value is not in the specified allowable
range.
33 SUB MAGENTA FRONT Result value error sub scan
MAGENTA F
The variation of the calculation result value is over the
specified allowable range.
35 SUB MAGENTA REAR Number error sub scan MAGENTA
R
The number of pitch data is not the specified number.
36 SUB MAGENTA REAR Pitch error sub scan MAGENTA R The pitch data is not in the specified allowable range.
37 SUB MAGENTA REAR Adjustment value error sub scan
MAGENTA R
The calculation result value is not in the specified allowable
range.
38 SUB MAGENTA REAR Result value error sub scan
MAGENTA R
The variation of the calculation result value is over the
specified allowable range.
40 SUB YELLOW FRONT Number error sub scan YELLOW F The number of pitch data is not the specified number.
41 SUB YELLOW FRONT Pitch error sub scan YELLOW F The pitch data is not in the specified allowable range.
42 SUB YELLOW FRONT Adjustment value error sub scan
YELLOW F
The calculation result value is not in the specified allowable
range.
43 SUB YELLOW FRONT Result value error sub scan
YELLOW F
The variation of the calculation result value is over the
specified allowable range.
45 SUB YELLOW REAR Number error sub scan YELLOW R The number of pitch data is not the specified number.
46 SUB YELLOW REAR Pitch error sub scan YELLOW R The pitch data is not in the specified allowable range.
47 SUB YELLOW REAR Adjustment value error sub scan
YELLOW R
The calculation result value is not in the specified allowable
range.
48 SUB YELLOW REAR Result value error sub scan
YELLOW R
The variation of the calculation result value is over the
specified allowable range.
