MX3500N SIMULATION 7 – 113
* When [OK] button is pressed, the display is shifted to the top
menu screen.
<Data display item and description>
51
51-1
Purpose
Adjustment
Function (Purpose)
Used to adjust the ON/OFF timing of the
transfer voltage and the separation bias
voltage.
Section
Process
Item
Operation (Transfer)
Operation/Procedure
1) Select the set item with [↑] and [↓] buttons.
The highlighted section of the set value is switched and dis-
played on the set setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
Adjustment item
(page)
Item display Display content
Display range (difference from the
previous value)
Unit
OC⋅SPF OC (1) ADJ_OC
(SCAN/LEAD/OFST)
OC adjustment value, correction
value
1 to 99 (–99 to +99) STEP
SCAN (F/C/R)/LEAD (F/C/R) OC magnification ratio, lead
edge data
SCAN: –4.99 to +4.99
LEAD: –4.9 to +4.9
SCAN: %
LEAD: mm
DATA_OFFSET
R (U/M/L)/F (U/M/L)
OC off-center data –4.9 to +4.9 mm
SCAN_MAIN OC Main scan magnification ratio
correction value
–4.99 to +4.99 %
SPF1 (2) ADJ_SPF1
(SCAN/LEAD/OFST)
SPF1 adjustment value,
correction value
1 to 99 ( ± 99) STEP
SCAN (F/C/R)/LEAD (F/C/R) SPF1 magnification ratio, lead
edge data
SCAN: –4.99 to +4.99
LEAD: –4.9 to +4.9
SCAN: %
LEAD: mm
DATA_OFFSET
R (U/M/L)/F (U/M/L)
SPF1 off-center data –4.9 to +4.9 mm
SCAN_MAIN SPF1 main scan magnification
ratio correction value
–4.99 to +4.99 %
SPF2 (3) ADJ_SPF2
(SCAN/LEAD/OFST)
SPF2 adjustment value,
correction value
1 to 99 (± 99) STEP
SCAN (F/C/R)/LEAD (F/C/R) SPF2 magnification ratio, lead
edge data
SCAN: –4.99 to +4.99
LEAD: –4.9 to +4.9
SCAN: %
LEAD: mm
DATA_OFFSET
R (U/M/L)/F (U/M/L)
SPF2 off-center data –4.9 to +4.9 mm
SCAN_MAIN SPF2 main scan magnification
ratio correction value
–4.99 to +4.99 %
Status (4) PAPER (OC/SPF1/SPF2) Paper information A4, A4R, A3, LT, LTR, WL –
COUNT (OC/SPF1/SPF2) Counter 0 to 255 Times
ERROR Error history – Error code
BK-MAG ADJ (BK-MAG)/PAPER/
COUNT
BK-MAG adjustment value,
correction value
ADJ: 1 to 199 (–199 to +199) ADJ STEP
PAPER: -
COUNT: Times
PAPER_SCAN DEVICE: OC, SPF1, SPF2
PAPER_PAPER_SIZE: A4, A4R, A3, LT,
LTR, WL PAPER_CS: MFT,CS1,CS2, CS3,
CS4,LCC PAPER_PRINT_DIR: F, R, U, L
COUNT: 0 to 255
BK-MAG BK-MAG data -9.99 to +9.99 mm
SCAN_MAG (SUB, MAIN) BK-MAG scan magnification ratio
correction value
SUB:-99 to +99
MAIN:-4.99 to +4.99
SUB:MAIN:-4.99
to +4.99
ERROR Error history – Error code
PRINT ADJ_MFT (LEAD/OFST) PRINT adjustment value,
correction value
LEAD,OFST:-4.9 to +4.9 PAPER_SCAN
DEVICE: LEAD, OFST: OC, SPF1, SPF2
PAPER_PAPER_SIZE: A4, A4R, A3, LT,
LTR, WL
PAPER_PRINT_DIR: F, R, U, L COUNT: 0
to 255
LEAD, OFST: mm
PAPER: –
COUNT: Times
LEAD (F/C/R) PRINT lead edge data -4.9 to +4.9 mm
OFFSET R (U/M/L)/F (U/M/L) Off-center data -4.9 to +4.9 mm
ERROR Error history – Error code
0
SIMULATION
NO.50
28
TEST
AUTO IMAGE POSITION ADJUSTMENT㧦SERVICE
CLOSE
ADJ_OC (SCAN / LEAD / OFST) 㧦50(r99) / 50(r99) / 50(r99)
SCAN(F /C /R) / LEAD(F /C /R)
㧦r4.99 /r4.99 /r4.99 , r4.9 /r4.9 /r4.9
OFFSET R(U /M /L) / F(U /M /L)
㧦r4.9 /r4.9 /r4.9 , r4.9 /r4.9 /r4.9
SCAN_MAIN
㧦r4.99
BK-MAG
OC
SPF
PRINT
OK
To Next Page
