FACSIMILE►BASIC TRANSMISSION METHODS
THE SIZE OF THE PLACED ORIGINAL
When a standard size original is placed, the original size is automatically detected and displayed in "Scan Size" on the
base screen.
► AUTO DETECTION (page 4-44)
Standard sizes are sizes that the machine can automatically detect. The standard sizes are set in "Original Size
Detector Setting" in setting mode.
List of original size detector settings
* In the size notation above, when the size is suffixed by "R" like "A4R", it indicates a case where a sheet available in
both the vertical and horizontal orientations are set horizontally.
When the automatic original detection function is operating and the original (of inch or non-standard size) is placed, the
closest size may be displayed or the original size may not appear. In this event, manually set the correct original size.
► SPECIFYING THE ORIGINAL SCAN SIZE IN PAPER SIZE (page 4-45)
► SPECIFYING THE ORIGINAL SCAN SIZE USING NUMERIC VALUES (page 4-46)
To specify the size that the machine can automatically detect:
In "Settings (administrator)", select the group of detected original sizes in [System Settings]→ [Common Settings] → [Device
Control] → [Original Size Detector Setting].
Selections
Standard sizes (detected original sizes)
Document glass Document feeder tray
(automatic document feeder)
Inch-1 11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R,
5-1/2" x 8-1/2"
11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R,
5-1/2" x 8-1/2", A3, A4
Inch-2 11" x 17", 8-1/2" x 13" (216 mm x 330 mm),
8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2"
11" x 17", 8-1/2" x 13" (216 mm x 330 mm),
8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2", A3, A4
Inch-3 11" x 17", 8-1/2" x 13-2/5" (216 mm x 340 mm),
8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2"
11" x 17", 8-1/2" x 13-2/5 (216 mm x 340 mm),
8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2", A3, A4
AB-1 A3, A4, A4R, A5, B4, B5, B5R A3, A4, A4R, A5, B4, B5, B5R, 11" x 17", 8-1/2" x 14",
8-1/2" x 11"
AB-2 A3, A4, A4R, A5, B5, B5R, 216 mm x 330 mm
(8-1/2" x 13")
A3, A4, A4R, A5, B4, B5, B5R, 216 mm x 330 mm
(8-1/2" x 13"), 11" x 17", 8-1/2" x 11"
AB-3 A4, A4R, A5, B4, 8K, 16K, 16KR A3, A4, A4R, A5, B4, 8K, 16K, 16KR, 11" x 17",
216 mm x 330 mm (8-1/2" x 13"), 8-1/2" x 11"
AB-4 A3, A4, A4R, A5, B5, B5R, 216 mm x 340 mm
(8-1/2" x 13-2/5")
A3, A4, A4R, A5, B4, B5, B5R, 11" x 17",
216 mm x 340 mm (8-1/2" x 13-2/5"), 8-1/2" x 11"
AB-5 A3, A4, A4R, A5, B5, B5R, 216 mm x 343 mm
(8-1/2" x 13-1/2")
A3, A4, A4R, A5, B4, B5, B5R, 11" x 17",
216 mm x 343 mm (8-1/2" x 13-1/2"), 8-1/2" x 11"
