Sharp MX-8090N Start Guide

16
Scan speed Copy mode B/W: 80 one-sided sheets/minute
(600 x 400 dpi)
Color: 53 one-sided sheets/minute
(600 x 600 dpi)
• When scanning one-sided, 8-1/2" x 11" (A4)
vertical documents
Scan mode
(300 dpi)
B/W: 100 sheets/minute (one-sided),
200 pages/minute (two-sided),
Color: 100 sheets/minute (one-sided),
200 pages/minute (two-sided),
• When in standard mode using Sharp
standard paper (8-1/2" x 11" (A4) size with
6% coverage) and the auto color detector is
turned off. The speed varies depending on
the data volume of the original.
Multi Bypass Tray
Name Multi Bypass Tray (MX-MF11)
(For large capacity trays)
Paper sizes
13" x 19" to 5-1/2" x 8-1/2"R (A3 wide to A5R) ,SRA3, SRA4
Useable paper 13 lbs bond to 80 lbs cover (55 to 220 g/m
2
)
Paper capacity
500 sheets (20 lbs (80 g/m
2
))
(or maximum stack height of 2-11/64" (55 mm))
Required power
supply
Supplied from large capacity trays
Dimensions When paper tray is closed
27-3/4" (W) x 21-57/64" (D) x 8" (H)
(705 mm (W) x 556 mm (D) x 203 mm (H))
When paper tray is pulled out
34-9/16" (W) x 21-57/64" (D) x 8" (H)
(878 mm (W) x 556 mm (D) x 203 mm (H))
Weight Approx. 39.7 lbs (18 kg)
Large Capacity Tray
Name Large Capacity Tray
(MX-LC12)
Large Capacity Tray
(MX-LCX3 N)
Paper sizes 8-1/2" x 11", A4, B5 13" x 19" to 8-1/2" x 11"R
(A3 wide to B5)
Useable paper 16 lbs bond to 80 lbs cover
(60 to 220 g/m
2
)
16 lbs bond to 80 lbs cover
(60 to 220 g/m
2
)
Paper capacity 3500 sheets
(20 lbs (80 g/m
2
))
3000 sheets
(20 lbs (80 g/m
2
))
Required power
supply
Supplied from the machine Supplied from the machine
Dimensions 14-13/16" (W) x 22-43/64"
(D) x 20-5/8" (H)
(376 mm (W) x 576 mm (D) x
524 mm (H))
26-3/8" (W) x 22-7/16" (D) x
20-43/64" (H)
(670 mm (W) x 570 mm (D) x
525 mm (H))
Weight Approx. 63 lbs (28.5 kg) Approx. 110 lbs (50 kg)
Large Capacity Trays
Name Large Capacity Trays (MX-LC13 N)
Paper sizes 13" x 19" to 8-1/2" x 11" (A3 wide to B5R) ,SRA3, SRA4
Useable paper 13 lbs bond to 110 lbs cover (55 to 300 g/m
2
)
Paper capacity 5000 sheets (2500 x 2 20 lbs (80 g/m
2
))
Required power
supply
AC 120V/15A ,60Hz
Dimensions 35-1/4" (W) x 30-1/32" (D) x 38-13/16" (H)
(895 mm (W) x 763 mm (D) x 986 mm (H))
Weight Approx. 288 lbs (131 kg)
Finisher (100-sheet stapling) /
Saddle Stitch Finisher
(100-sheet stapling)
Name Finisher (MX-FN21)
Saddle Stitch Finisher (MX-FN22)
Paper sizes Depends on feeder specifications
Useable paper Paper weight 13 lbs. to 110 lbs. Cover (55 g/m
2
to 300 g/m
2
)
No. of trays MX-FN21: 3 (Upper tray / Middle tray / Lower tray)
MX-FN22: 4 (Upper tray / Middle tray / Lower tray) + Saddle
stitch tray
Tray capacity
(20 lbs. bond
(80g/m
2
))*
Upper tray
Non-stapled 13" x 19", 12" x 18", 9" x 12", 11" x 17",
8-1/2" x 14", 8-1/2" x 11"R,
7-1/4" x 10-1/2"R (SRA3, SRA4, A3 wide,
A4 wide, A3, B4, A4R, B5R): 750 sheets
8-1/2" x 11", 5-1/2" x 8-1/2"R (A4, B5,
A5R): 1500 sheets
Staple function 11" x 17", 8-1/2" x 14", 8-1/2" x 11"R (A3,
B4, A4R): 50 units or 750 sheets
8-1/2" x 11" (A4, B5): 100 units or 1500
sheets
Middle tray
Non-stapled 13" x 19", 12" x 18", 9" x 12", 11" x 17",
8-1/2" x 14", 8-1/2" x 11"R,
7-1/4" x 10-1/2"R (SRA3, SRA4, A3 wide,
A4 wide, A3, B4, A4R, B5R): 125 sheets
8-1/2" x 11", 5-1/2" x 8-1/2"R (A4, B5,
A5R): 250 sheets
(Offset output is not available)
Lower tray
Non-stapled 13" x 19", 12" x 18", 9" x 12", 11" x 17",
8-1/2" x 14",8-1/2" x 11"R, 7-1/4" x
10-1/2"R (SRA3, SRA4, A3 wide, A4
wide, A3, B4, A4R, B5R,): 750 sheets
8-1/2" x 11", 5-1/2" x 8-1/2"R (A4, B5,
A5R): 1500 sheets
8-1/2" x 11" (A4, B5): 2450 sheets
(Offset output is not available)
Staple function 11" x 17", 8-1/2" x 14", 8-1/2" x 11"R (B4, A3,
A4R): 50 units or 750 sheets
8-1/2" x 11" (A4, B5): 100 units or 1500 sheets
Saddle stitch tray (MX-FN22)
Non-stapled 16 lbs bond to 28 lbs bond (60 to
105 g/m
2
): 5 sheets
Staple function 16 lbs bond to 21 lbs bond (60 to
81.4 g/m
2
): 5 units (16 to 20 sheets), 10
units (11 to 15 sheets), 15 units (6 to 10
sheets), 25 units (1 to 5 sheets)
21 lbs bond over to 28 lbs bond
(81.4 g/m
2
over to 105 g/m
2
): 15 units (6
to 10 sheets), 25 units (1 to 5 sheets)
Staple function 16 lbs bond to 21 lbs bond (60 to
in cover mode 81.4 g/m
2
): 5 units (16 to 20 sheets),
10 units (1 to 15 sheets)
21 lbs bond over to 28 lbs bond
(81.4 g/m
2
over to 105 g/m
2
): 10 units
(1 to 10 sheets)
• Offset output is not available for 13" x 19", 12" x 18" /
7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R (A3 wide, B5R, A5R).
Max. no. of
stapled sheets
(20 lbs. bond
(80g/m
2
))
Max. no. of 100 sheets (8-1/2" x 11" (A4, B5))
Max. no. of 50 sheets (11" x 17", 8-1/2" x 14", 8-1/2" x 11"R
(A3, B4, A4R))
Staple position Front: 1 position (slant), Back: 1 position (slant),
Center: 2 positions
Saddle Stitch
(MX-FN22)
Staple method
(for saddle stitch)
Centered fold with stapling in 2 center places
Saddle stitch fold position
Centered fold
Saddle usable sizes
13" x 19", 12" x 18", 11" x 17", 8-1/2" x 14",
8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13",
8-1/2" x 11"R (SRA3, A3 wide, A3, B4, A4R)
Saddle usable paper weight
16 lbs bond (60 g/m
2
) to 110 lbs cover (300 g/m
2
)
Paper weighting 28 lbs bond (106 g/m
2
) to 110 lbs cover
(300 g/m
2
) is only able to be used in cover mode and for
single sheet fold.
Max. no. of saddle-stitched sheets
Max. no. of 20 sheets (20 lbs (80 g/m
2
)):
19 sheets (20 lbs bond (80 g/m
2
)) + 1 sheet (110 lbs cover
(300 g/m
2
))
