17
* Output capacity may vary depending on environmental conditions at the
installation location, the type of paper used, and the storage condition of the
paper.
Required power
supply
AC 120V/12A ,60Hz
Weight MX-FN21: Approx. 134.5 lbs (61 kg)
MX-FN22: Approx. 238.1 lbs (108 kg)
Dimensions MX-FN21:
When output paper tray is stored
25-3/4" (W) x 30-1/8" (D) x 40-15/16" (H)
(654 mm (W) x 765 mm (D) x 1040 mm (H))
When output paper tray is extended
30-51/64" (W) x 30-1/8" (D) x 40-15/16" (H)
(782 mm (W) x 765 mm (D) x 1040 mm (H))
MX-FN22:
When output paper tray is stored
30-13/64" (W) x 30-1/8" (D) x 40-15/16" (H)
(767 mm (W) x 765 mm (D) x 1040 mm (H))
When output paper tray is extended
35-9/32" (W) x 30-1/8" (D) x 40-15/16" (H)
(896 mm (W) x 765 mm (D) x 1040 mm (H))
Punch Module (100-sheet stapling)
Name Punch module (MX-PN13B)
Paper size for
punch module
11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5",
8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R (A3, A4, A4R)
Holes 2 holes / 3 holes (Auto select)
Required power
supply
Supplied from finisher/saddle stitch finisher
Dimensions 3-3/4" (W) x 28-9/64" (D) x 9-7/16" (H)
(95 mm (W) x 715 mm (D) x 392 mm (H))
Weight Approx. 8.6 lbs (3.7 kg)
Paper Pass Unit
Name Paper Pass Unit
(MX-RB12 N)
Paper Pass Unit (MX-RB14)
Dimensions 21-5/8" (W) x 20-9/16" (D) x
5-61/64" (H)
(549 mm (W) x 522 mm (D) x
151 mm (H))
18" (W) x 29-59/64" (D) x
41-27/64" (H)
(457 mm (W) x 760 mm (D) x
1052 mm (H))
Weight Approx. 13.5 lbs (6.1 kg) Approx. 60.7 lbs (27.5 kg)
Relay Unit
Name Relay Unit (MX-RB13)
Dimensions 8-7/16" (W) x 29-59/64" (D) x 38-13/16" (H)
(214 mm (W) x 760 mm (D) x 986 mm (H))
Weight Approx. 40 lbs (14.5 kg)
Curl Correction Unit
Name Curl Correction Unit (MX-RB15)
Paper sizes Depends on feeder specifications
Useable paper Depends on feeder specifications
Required power
supply
Supplied from the machine
Dimensions 8-7/16" (W) x 29-59/64" (D) x 38-13/16" (H)
(214 mm (W) x 760 mm (D) x 986 mm (H))
Weight Approx. 40.6 lbs (18.4 kg)
Trimming Module
Name Trimming module (MX-TM10)
Useable size for
trimming
module
13" x 19", 12" x 18" (A3 wide), 11" x 17", 8-1/2" x 14", 8-1/2"
x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11"R, SRA3,
A3, B4, A4R
Max. no. of
sheets to be
trimmed
1 to 20 sheets (16 lbs bond to 21 lbs bond (60 g/m
2
to
81.4 g/m
2
))
1 to 10 sheets (21 lbs bond over to 28 lbs bond (81.4 g/m
2
over to 105 g/m
2
))
1 to 3 sheets (28 lbs bond over to 80 lbs cover (105 g/m
2
over to 220 g/m
2
))
When plain paper trimmed. Including one front cover of 110
lbs cover (300 g/m
2
) or less.
Required power
supply
Supplied from saddle stitch finisher
Dimensions 9-7/8" (W) x 24-15/32" (D) x 15-7/8" (H)
(251 mm (W) x 625 mm (D) x 403 mm (H))
Weight Approx. 70.6 lbs (32 kg)
Folding Unit
Name Folding unit (MX-FD10)
Folding types Z-Fold, C-Fold, Accordion Fold, Double Fold, Half Fold.
Useable size for
folding unit
Z-Fold: 11" x 17", 8-1/2" x 14", 8-1/2" x 11"R, A3, B4, A4R
C-Fold, Accordion Fold, Double Fold, Half Fold:
8-1/2" x 11"R, A4R
Useable paper 13 lbs bond to 28 lbs bond (55 g/m
2
to 105 g/m
2
)
Tray capacity
(20 lbs (80 g/m
2
)) *
C-Fold/Accordion Fold/Double Fold
2-23/64" (60 mm) (Equivalent to 40 sheets. (Equivalent to 25
sheets for Double Fold))
Copies made in Z-Fold or Half Fold are output to the tray of
the finisher (100-sheet stapling) or saddle stitch finisher
(100-sheet stapling).
Required power
supply
Supplied from finisher/saddle stitch finisher
Dimensions 13-15/32" (W) x 30-5/16" (D) x 41-11/32" (H)
(336 mm (W) x 770 mm (D) x 1050 mm (H))
Weight Approx. 145.5 lbs (66 kg)
Inserter
Name Inserter (MX-CF11)
Useable size for
inserter
13" x 19", 12" x 18", 9" x 12", 11" x 17", 8-1/2" x 14", 8-1/2" x
13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x
11"R, 7-1/4 x 10-1/2"R, 5-1/2" x 8-1/2"R, A3 wide, A4 wide,
A3, B4, A4, A4R, B5, B5R, A5R, SRA3, SRA4
Useable paper 16 lbs bond to 80 lbs cover (60 g/m
2
to 220 g/m
2
)
No. of trays 2
Tray capacity
(20 lbs (80 g/m
2
))
Upper tray: 200 sheets
Lower tray: 200 sheets
Required power
supply
Supplied from the machine
Dimensions 21-1/4" (W) x 29-7/8" (D) x 50-1/4" (H)
(540 mm (W) x 760 mm (D) x 1276 mm (H))
Weight Approx. 99.2 lbs (45 kg)
Network Printer Specifications
Type Built-in type
Continuous print
speed
Same as continuous copy speed
Resolution Data processing: 600 x 600 dpi, 1200 x 1200 dpi
Print: 600 x 600 dpi, 1200 x 1200 dpi,
equivalent to 9600 dpi × 600 dpi
Page description
language
PCL6 emulation, Adobe
®
PostScript
®
3™
Compatible
protocols
TCP/IP (LPD, Port9100, IPP, SMB, FTP, WSD,
POP3<E-mail print>, HTTP)
Compatible OS Windows Server 2008, Windows 7, Windows 8.1,
Windows Server 2012, Windows 10, Windows Server 2016
Mac OS X (10.6, 10.7, 10.8, 10.9, 10.10, 10.11, 10.12)
Internal fonts 80 fonts for PCL, 139 fonts for Adobe
®
PostScript
®
3™
Memory Machine system memory and hard disk
Interface 10BASE-T/100BASE-TX/1000BASE-T
Network Scanner Specifications
Type Color scanner
Scan resolution
(main x vertical)
100 x 100 dpi, 150 x 150 dpi, 200 x 200 dpi, 300 x 300 dpi,
400 x 400 dpi, 600 x 600 dpi (push scan)
50 to 9600 dpi *
1
(pull scan)
Scan speed
(8-1/2" x 11"
(A4))
Refer to "Scan speed " in "Automatic Document Feeder".
Interface 10BASE-T/100BASE-TX/1000BASE-T,
USB 2.0 (when an external memory device is used)
