Sharp MX-C300W

TEST SIMULATION
SHARP
52
65
LCD Operation & Adjust
1
LCD touch panel adjustment [MX-C301W]
2
LCD touch panel adjustment result display
[MX-C301W]
5
Operation panel key input test [MX-C301W]
10
Displays key standby time [MX-C250/300]
66
Fax Control Settings & Adjustments
1
Fax Soft SW setting
SW24
Communication Signal sending
level (bits 1-8) [MX-C301W]:-
Default Value (Australia/NZ)
00001011
SW25,
1 to 5
Signal Sending Out Level
[MX-C250F/300W]:-
0(0dBm) - 26(-26dBm).
SW27-4,5
V.34 mode function
[MX-C250F/300W]:-
0 = OFF
1 = ON.
SW27-4
V.34 mode function (call
arrival) [MX-C301W]:-:-
0 = V.34 valid.
1 = V.34 invalid.
SW27-5
V.34 mode function (polling
when calling) [MX-C301W]:-:-
0 = V.34 valid.
1 = V.34 invalid.
SW27-6
V.34 mode function (manual
communication) [MX-C301W]:-
0 = V.34 valid.
1 = V.34 invalid.
SW33-6,7
Transmission cable amplitude
equaliser [MX-C301W]:-
00 = 0dB
01 = 4dB
10 = 8dB
11 = 12dB
2
Country code default set (Fax)
3
Fax PWB controller memory check
[MX-C301W]
4
Fax signal line check (Max level)
5
Fax signal line check (Soft SW setting level)
[MX-C301W]
6
Fax list print (confidential registration)
[MX-C301W]
7
Fax memory printout (all data)
8
Fax sound message setup
66
Fax Control Settings & Adjustments
9
Fax signal line check (Soft SW setting)
[MX-C301W]
10
Fax all memory clear
11
Voice signal check (line/speaker 300bps)
12
Voice signal check (line/speaker 300bps)
13
Register dial number for Sim 66-14/15/16
14
Adjust/check the time dial pulse (10bps)
[MX-C301W]
15
Adjust/check the time dial pulse (20bps)
[MX-C301W]
16
Adjust/check the send level DTFM signal
[MX-C301W]
17
DTFM signal to send to line (Max level)
18
DTFM signal to send to line (Soft Sw level)
[MX-C301W]
21
Print various registration information
22
Set the sound volume of the handset
[MX-C301W]
24
Fast memory data clear [MX-C301W]
29
Fax address book clear [MX-C301W]
30
Tel/LIU sensor status check
31
ON/OFF setting of output port (Tel/LIU)
32
Received data check (comparison)
33
Busy Tone/CNG/CED/FNET detect check
34
Display time required for sending test data
36
Check Send/Receive from modem.
[MX-C301W]
39
Check Destination saved in Fax EEPROM
[MX-C301W]
42
Rewrite PIC program installed on Fax box
[MX-C301W]
43
Write program & adjustment values to PIC
installed on Fax [MX-C301W]
61
Display FAX related soft switch (151-250)
[MX-C301W]
62
FAX receive data export in PDF format.
[MX-C301W]
67
Printer Settings & Adjustments
17
Printer NVRAM clear [MX-C301W]
24
Printer half tone auto adjustment
[MX-C301W]
25
Printer half tone colour adjustment
26
Standard target select of printer half tone
auto adjustment [MX-C301W]
27
Scanner target of printer calibration setup
(Service) [MX-C301W]
28
Standard target of printer colour
calibration (Service) [MX-C301W]
