6
Continuous
print speed
Same as continuous copy speed
Resolution
600 × 600 dpi, 1,200 × 600 dpi
Page description
language
PCL6 emulation, PS3 emulation*
Compatible
protocols
TCP/IP (IPv4/IPv6), IPX/SPX, EtherTalk
Compatible
OS
Windows Server 2003, Windows Vista,
Windows Server 2008, Windows 7, Windows 8,
Windows Server 2012
Macintosh (Mac OS X 10.4, 10.5, 10.6, 10.7, 10.8, 10.9)
Internal fonts
(options)
80 fonts for PCL, 136 fonts for PS3 emulation
Interface
10BASE-T/100BASE-TX/1000BASE-T
USB 2.0 (high speed mode)
* PS3 expansion kit is needed.
Printer Specifications
Type
Colour scanner
Scan
resolution
100 × 100 dpi, 200 × 200 dpi, 300 × 300 dpi, 400 × 400 dpi,
600 × 600 dpi (push scan)
50 to 9,600 dpi *1 (pull scan *2)
Scan speed
(A4 (8-1/2” × 11”))
(200 × 200 dpi)
(one-sided)
56 sheets/minute
When in standard mode using Sharp standard paper
(A4 (8-1/2" × 11") size with 6% coverage) and the
auto colour detector is turned off. The speed varies
depending on the data volume of the original.
Interface
10BASE-T/100BASE-TX/1000BASE-T,
USB 2.0 (during USB memory scanning)
Compatible
protocols
TCP/IP (IPv4)
Compatible
OS *3
Pull scan (TWAIN)
Windows Server 2003, Windows Vista, Windows Server 2008,
Windows 7, Windows 8, Windows Server 2012
Output format
(B/W)
TIFF, PDF, PDF/A, encrypted PDF, XPS*4
Compression method
: decompression, G3 (MH), G4 (MMR)
(Grey scale/colour)
TIFF, JPEG, PDF, PDF/A, encrypted PDF, XPS*4
Compression method: JPEG (high, mid, and low compression)
Driver
TWAIN compliant
*1 You must decrease the scan size when increasing the resolution.
*2 Hard disk expansion kit is needed.
*3 There are cases when a connection cannot be established.
Please contact your local dealer for more information.
*4 XPS stands for XML Paper Specification.
Network Scanner Specifications
Model
Facsimile expansion kit (MX-FX11)
Useable lines
General phone lines (PSTN), automated branch exchange (PBX)
Connection speed
Super G3: 33.6 kbps, G3: 14.4 kbps
Coding method
MH, MR, MMR, JBIG
Connection
mode
Super G3 / G3
Original paper
sizes for
transmission
A3 to A5 (11” × 17” to 5-1/2” × 8-1/2”) (Paper with a max.
length of 1,000 mm* can be transmitted (one-sided only).)
* Internet fax (optional) is up to 800 mm (at 600 x 600 dpi).
Registered
paper size
A3 to A5 (11” × 17” to 5-1/2” × 8-1/2”)
Transmission
time
Approx. 2 seconds * (A4 (8-1/2" × 11") Sharp standard
paper, normal characters, Super G3 (JBIG))
Memory
Without HDD 512MB
With HDD 1GB
Notes
Touch dial memory Max. 1,000 entries (Including group
dialing for fax, scanner, and Internet
fax)
Group dial Max. of 500 entries
Mass transmissions Max. of 500 recipients
* Complies with the 33.6 kbps transmission method for Super G3 facsimiles
standardized by the International Telecommunications Union (ITU-T). This
is the speed for when sending an A4 (8-1/2" × 11") size piece of paper
of around 700 characters at standard image quality (8 × 3.85 line/mm)
in Hi-speed mode (33.6 kbps). This is the transmission speed for image
information only and does not include time for transmission control. The
actual time needed for a transmission depends on the content of the text,
type of receiving fax machine, and telephone line conditions.
Fax Specifications
Document
feeder types
Reversing Single Pass Feeder (RSPF)
Original paper
sizes
A3 (11” × 17”) to A5 (5-1/2” × 8-1/2”)
Original paper
types
Paper weight
Thin paper 35 g/m
2
(9 lbs. bond) to 49 g/m
2
(13 lbs. bond)
Plain paper 50 g/m
2
(13 lbs. bond) to 128 g/m
2
(34 lbs. bond)
Two-sided 50 g/m
2
(13 lbs. bond) to 105 g/m
2
(28 lbs. bond)
Paper storage
capacity
100 sheets (80 g/m
2
(21 lbs. bond))
(or maximum stack height of 13 mm (1/2”))
Scan speed
(copy)
(600 × 400 dpi)
56 sheets/minute
When scanning one-sided, A4 (8-1/2” × 11”) vertical
documents
Model
Stand (large) (AR-DS19) Stand (small) (AR-DS20)
Dimensions
599 mm (W) x 550 mm (D) x
301 mm (H)
(22-19/32” (W) x 21-21/32” (D)
x 11-55/64” (H))
599 mm (W) x 550 mm (D) x
101 mm (H)
(22-19/32” (W) x 21-21/32” (D)
x 3-63/64” (H))
Weight
Approx. 10 kg (22.0 lbs.) Approx.5 kg (11.0 lbs.)
Automatic document feeder
Stand (Optional)
Model
500-sheet paper tray
(MX-CS12)
500-sheet paper tray
(MX-CS13)
Paper sizes
A3, B4, A4, A4R, B5, B5R, A5R, 11”×17”, 8-1/2”×14”,
8-1/2”×13-1/2”, 8-1/2”×13-2/5”, 8-1/2”×13”, 8-1/2”×11”,
8-1/2”×11”R, 5-1/2”×8-1/2”R
Useable paper
55 g/m
2
(13 lbs. bond) to 105 g/m
2
(28 lbs. bond)
Paper capacity
500 sheets Using 80 g/m
2
(21 lbs.) weight paper
Dimensions
599 mm (W) × 566 mm (D) × 139 mm (H)
(23-19/32” (W) × 22-19/64” (D) × 5-31/64” (H))
Weight
Approx. 5.9 kg (13.0 lbs.) Approx. 6.2 kg (13.7 lbs.)
Drawer (Optional)
Finisher
Name
Finisher (MX-FN26)
Paper sizes
Depends on feeder specifications
Useable paper
55 g/m
2
(13 lbs. bond) to 200 g/m
2
(110 lbs. cover)
Number of trays
1 Tray
Tray capacity
(80g/m
2
(21 lbs.))
Non-stapled
A3 (11” × 17”) / B4 (8-1/2” × 14”): 250 sheets
A4 (8-1/2” × 11”) / A4R (8-1/2” × 11”R) / B5 /
B5R
/ A5R (5-1/2” × 8-1/2”R):
500 sheets
Staple function
A3 (11” × 17”) / B4 (8-1/2” × 14”): 30 units or 250 sheets
A4 (8-1/2” × 11”) /A4R (8-1/2” × 11”R) / B5 / B5R:
30 units or 500 sheets
Offset output is not available for B5R (7-1/4” × 10-1/2”R) /
A5R (5-1/2” × 8-1/2”R).
Max. number of
stapled sheets
(90g/m
2
(24lbs.))
Max. number of 50 sheets
(A4 (8-1/2” × 11”), A4R (8-1/2” × 11”R),
B5, B5R)
Max. number of 30 sheets
(A3 (11” × 17”), B4 (8-1/2” × 14”))
Staple position
1 top
Required
power supply
Supplied from this machine
Weight
Approx. 13 kg (28.7 lbs.)
About password management
It is requested to change the administrator password right after installing the
machine. The password should be changed by the administrator and strictly
managed. Write down the changed password in the following table and keep it
carefully.
Please write "New Password".
Factory default New Password
Administrator
password
admin
Please take care not to forget newly set administrator password. If
it is forgotten there is no way to confirm it and some settings and
functions that require administrator authorization may not be used.
Dimensions
When output paper tray is stored
472 mm (W) × 458 mm (D) × 199 mm (H)
(18-19/32” (W) × 18-3/64” (D) × 7-27/32” (H))
When output paper tray is extended
619 mm (W) × 458 mm (D) × 199 mm (H)
(24-3/8” (W) × 18-3/64” (D) × 7-27/32” (H))
