Coin Vend Interface
12
DocumentSolutionsAfterSalesService
The coin vend interface for the MX-M264/314/354 machines is located on the PCU
PWB. Before connecting a third party auditor, the device must conform to the
following specifications:
1. The auditor interface should be optically isolated from the copier.
2. The external auditor interface should be ‘Power Supply Unit’ independent.
3. supply.
4. The external auditing device’s plug-top adapter should have a reinforced
insulation barrier.
5. The external auditing device must ‘hold’ a CE mark.
To enable coin vend function, execute Simulation 26-03.
During duplex copy mode, the interface will issue 2 billing pulses for each duplex
copy irrespective of the size of the paper used (e.g. an A4 duplex copy will generate
2 billing pulses and an A3 duplex copy will also generate 2 billing pulses). In order
for the external auditing device to detect the selected paper size, the paper size
outputs on pin’s 1 to 4 must also be used.
Note: The configuration of the external auditor connector (CN133) may differ
slightly from that of other models, so it is important to ensure that the correct
cable/connections are used.
Connector Signals
Pin
No
Signal Name Details
1 +24 V dc
2 P-GND
3 +24 V dc
4 GND
5 /CV_COUNT Paper exit copy signal (Late billing pulse)
6 /CV_COPY Enables ready status of copier
7 /CV_START
Copy start paper feed clutch signal (Early
billing pulse)
8 /AUD_PNC
9 /CV_CA Clear-all Signal
10 /AUD_COPY
11 /CV_DPX Duplex signal
12 /AUD_CA
13 /CV_SIZE0 Copy paper size indicator
14 /AUD_READY
15 /CV_SIZE1 Copy paper size indicator
16 /AUD
17 /CV_SIZE2 Copy paper size indicator
18 /PNC_a
19 /CV_SIZE3 Copy paper size indicator
20 GND
