Replacing the staple cartridge (saddle stitch unit)
Before starting this procedure, remove all output from the output tray of the saddle finisher (large
stacker). Do not replace removed output back in the output tray.
Open the front cover.
Grasp the handle on the saddle stitch unit and pull it slowly out until it stops.
Pull the staple unit in the saddle stitch unit out and then rotate it up.
Make a proof copy in staple sort function to verify that stapling takes place correctly.
