MX-M700N SIMULATION 7 – 46
48
48-1
Purpose
Adjustment
Function (Purpose)
Used to adjust the copy magnification ratio
(in the main scanning and the sub scanning
directions).
Section
Optical (Image scanning)
Operation/Procedure
(Adjustment mode selection)
1) Select the number corresponding to the copy mode to be
adjusted with 10-key. (Select one of 3 - 7.)
2) Press the [START] key.
(Copy magnification ratio adjustment)
1) Select the number corresponding to the copy magnification
ratio adjustment mode to be adjusted with 10-key. (Select one
of 3 - 7.)
2) Press the [START] key.
3) Enter the copy magnification ratio adjustment value with 10-
key.
4) Press the [P] or [START] key.
When [START] key is pressed, copy is performed and the
adjustment value is set simultaneously.
The copy magnification ratio in the sub scan direction can be
adjusted by changing the scan speed (motor RPM).
The greater the value is, the greater the correction is. One step cor-
responds to 0.1% adjustment.
(Copy condition setting in this simulation)
* To select paper (paper feed tray), perform the following proce-
dures.
1) Enter 0 with 10-key.
2) Press [START] key. (The mode is changed to the paper feed
tray selection mode.)
3) Enter the number corresponding to the paper feed tray to be
used with 10-key. (Select one of 1 - 6.)
4) Press [START] key. (The paper feed tray is selected.)
When the total of the above set value (1 - 6) and 10 is entered, the
mode is changed to the duplex mode.
* The copy magnification ratio can be set with the following
1) Enter 2 with 10-key.
2) Press the [START] key.
3) Enter the copy magnification ratio with 10-key.
4) Press the [START] key.
NOTE: When [P] key is pressed after entering an adjustment value
in this simulation, the adjustment value is set. When
[START] key is pressed, the adjustment value is set and
copying is performed.
48-5
Purpose
Adjustment
Function (Purpose)
Used to adjust the copy magnification ratio
in the sub scanning direction.
Section
Optical (Image scanning)
Operation/Procedure
When the sub scanning direction image magnification ratio adjust-
ment with SIM 48-1 cannot provide a satisfactory result if a different
magnification ration is set and a copy is made, perform this simula-
tion.
When there is an error in the copy magnification ratio in reduction
copy, change the adjustment value of the high speed mode. When
there is an error in the copy magnification ratio in enlargement
copy, change the adjustment value of the low speed mode.
1) Select the number that corresponds to the mode for which to
make adjustments with 10-key.
2) Press the [START] key.
3) Enter the copy adjustment value with 10-key.
The scanner/SPF motor rotation sped adjustment value is
entered.
Item
Setting
range
Default
0 TRAY SELECT Paper feed tray
selection
0 - 99 50
1 COPY START Copy START (Default)
2 MAGNIFICATION Print magnification
ratio
3 CCD (MAIN) SCAN main scanning
magnification ratio
adjustment (CCD)
4 CCD (SUB) SCAN sub scanning
magnification ratio
adjustment (CCD)
5 SPF (SUB) SPF front surface
magnification ratio
adjustment (Sub scan)
6 CIS (MAIN) SPF back surface
magnification ratio
adjustment
(CIS main scan)
7 SPF (MAIN) SPF front surface
magnification ratio
adjustment
(Main scan)
Normal display NOW COPYING.
ERROR display Door open DOOR OPEN.
Jam JAM
Paper empty PAPER EMPTY.
1TRAY1 TRAY1
2TRAY2 TRAY2
3TRAY3 TRAY3
4TRAY4 TRAY4
5 BPT Manual paper feed
6 LCC Side LCC
Setting range 25 - 400 (%)
Item Content
Setting
range
Default
0 MIR (220) Scanner motor
(220mm/sec)
0 - 99 50
1 MIR (110) Scanner motor
(110mm/sec)
2 SPF (360) SPF motor
(360mm/sec)
3 SPF (220) SPF motor
(220mm/sec)
4 SPF (110) SPF motor
(110mm/sec)
2
SIMULATION 48-1
MAGNIFICATION ADJUSTMENT. SELECT 0-7, AND PRESS START.
0.TRAY SELECT 1 1.PRINT START
2.MAGNIFICATION 100
3.CCD(MAIN) 50 4.CCD(SUB) 50 5.SPF(SUB) 50
6.CIS(MAIN) 50 7.SPF(MAIN) 50
To Next Page
