Sharp MX-M550U

MX-M700N DUPLEX SECTION H – 12
v. Reversing discharge brush
1) Pull out the left door.
2) Remove the switchback gate.
3) Remove the reversing discharge bursh.
* Attach the reverse discharge brush so that it is fit with the rib
inside and the parting line.
4. Maintenance
✕: Check {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shift position
(Clean, replace, or adjust according to necessity.)
55ppm (PM: 250K)
When
calling
250
K
500
K
750
K
1000
K
1250
K
1500
K
1750
K
2000
K
Remark/Refer to the
Parts Guide.
Block/Item No.
(Only the replacement
parts are described.)
62ppm/70ppm (PM: 300K)
300
K
600
K
900
K
1200
K
1500
K
1800
K
2100
K
2400
K
Unit name No. Part name
Duplex 1 Transport rollers ✕ {{{{{{{{
2 Transport paper guides { {{{{{{{{
3 Discharge brush ✕ ✕✕✕✕✕✕✕✕
2
1
1
1
1
3
3
