Sharp MX-M623N

MAINTENANCE
SHARP
14
Maintenance Schedule
300k
Maintenance:
Process Section:
Replace Black Developer (MX-753GV – 1 bag only)
Replace Black Drum (AR-620DM)
Use Stearic Acid Starting Powder (UKOG-0312FCZZ)
Replace MX-753KA Maintenance Kit 1:-
 Drum Cleaner Blade
 Drum Separation Pawl x 4
 MC Screen Grid
 Toner Reception Seal
 Charging Plate
 Paper Dust Removal Unit
 Doctor Cover Unit
 DV Side Seal F
 DV Side Seal R
 MC Cleaning Unit
Replace Ozone Filters.
 Ozone Filter (PFiLZ0273FCZ1)
 Ozone Filter (PFiLZ0298FCZZ)
 Toner Filter (PFiLZ0272FCZZ)
Sim 24-05 Clear Developer Counter
Sim 24-07 Clear Drum Counter
Sim 25-02 Toner Concentration Adjustment
Sim 24-04 Clear Maintenance Counter
Fuser Section:
Replace MX-753KC Fuser Maintenance Kit:-
 Upper Heat Roller
 Crimping Roller EX
 Insulation Spacer x 4
 Bush (Heat-safe) x 2
 Upper Seaparation Pawl x 4
 Web Roller DG2
 Pressure Roller DG2
 Web Bearing x 2
 Pressure Bearing x 2
 Pressure SP x 2
 Lower Web Roller
 Lower Web Pressure Roller
 Lower Web Pressure Bearing x 2
 Lower Web Pressure SP x 2
