MX-M753N MX-CF10 4 – 3
B. When the finisher or the saddle finisher is
installed
* If it is not installed, perform procedure C..
(1) Removal of the connector between the main unit
and the finisher
1) Remove the screw from the finisher connector connected to
the left side of the main unit.
2) Disconnect the finisher connector.
(2) Removal of the rail, the connectting plate, and the
earth plat
1) Separate the finisher and the main unit.
2) Remove two screws which are fixing the connecting plate
under the finisher.
3) Remove the plate (fixed by one screw) from the rear lower sec-
tion of the finisher.
4) Go to procedure D..
C. When the finisher and the saddle finisher are
not installed to the main unit
(1) Attach the positioning pin and the earth plate to
the main unit. (Use the packaged parts of the
finisher.)
1) Remove the connector cover fixing screw for connection of the
finisher joint harness connector, and remove the connector
cover.
* Only when the finisher and the inserter are installed
together, perform this procedure.
1
2
To Next Page
