MX-M753N MX-FN14 7 – 2
10) Carefully remove the finisher from the pallet.
B. Removal of the fixing member
Remove the tape from the finisher.
Remove the shipment locking material with red note.
1) Remove the tape and fixing member.
2) Remove the screw, and remove lift tray rail section transit fix-
ing members (4 positions).
C. Check the packed items
1) Check that all the items are included in the package.
2. Installation
<Note before installation>
* Before starting installation, check to insure that the data lamp on
the operation panel is not on or blinking.
A. Turn off the power of the main unit
1) Turn OFF the power switch on the operation panel.
2) Open the front cabinet.
Turn OFF the power switch in the front cabinet of the main unit.
3) Disconnect the power plug of the main unit from the power out-
let.
1 Positioning pin 1 pc. 7 Screw H (M4 x 14) 2 pcs.
2 Earth plate 1 pc. 8 Screw I (M4 x 18) 4 pcs.
3 Earth mounting plate 1 pc. 9 Staple cartridge 1 pc.
4 Rail mounting plate 1 pc. 10 Clamp 1 pc.
5 Staple label 2 pcs. 11 Power code 1 pc.
6 Screw G (M4 x 8) 3 pcs. 12 Punch position label 2 pcs.
