MX-M753N MX-CF10 4 – 7
3) Connect the inserter relay harness connector to the main unit
connector, and tighten the connector screw to fix the connec-
tor.
J. Install the inserter to the main unit
1) Bring the inserter closer to the main unit.
2) Check that the main unit positioning pin enters smoothly into
the center of the inserter positioning guide.
(1) When the positioning pin does not enter smoothly
1) Loosen the adjustment section fixing screws (2 pcs.) on the
rear side.
2) Turn and adjust the rear side height adjustment bolt so that the
center height of the positioning pin comes at the center of the
positioning guide.
3) Tighten two fixing screws of the rear side adjustment section.
4) Loosen the front side adjustment section fixing screws (2 pcs.)
5) Turn and adjust the front side height adjustment bolt so that it
is at the same position with the rear side adjustment section
fixing screw.
6) Tighten two fixing screws of the front side adjustment section.
To Next Page
