Sharp MX-M654N

10
Punch Module
Name Punch module for MX-FN19/
MX-FN20
MX-PN12A, MX-PN12B,
MX-PN12C, MX-PN12D
Punch module for MX-FN21/
MX-FN22
MX-PN13A, MX-PN13B,
MX-PN13C, MX-PN13D
Paper size for
punch module
A3 (11" × 17") to B5R (7-1/4" × 10-1/2"R)
Holes MX-PN12A: 2 holes,
MX-PN12B: 3 holes,
MX-PN12C: 4 holes,
MX-PN12D: 4 holes (wide)
MX-PN13A: 2 holes,
MX-PN13B: 3 holes,
MX-PN13C: 4 holes,
MX-PN13D: 4 holes (wide)
Required power
supply
Supplied from Finisher/Saddle stitch nisher
Dimensions 102 mm (W) × 662 mm (D) ×
914 mm (H)
(4-1/64" (W) × 26-1/16" (D) ×
35-63/64" (H))
95 mm (W) × 715 mm (D) ×
392 mm (H)
(3-3/4" (W) × 28-9/24 (D) ×
15-7/16" (H))
Weight Approx. 8 kg (17.7 lbs.) Approx. 3.7 kg (8.2 lbs.)
Inserter
Name Inserter (MX-CF11)
Useable size for
inserter
A3W (12" × 18"), A3, B4, A4, A4R, B5, B5R, A5R, 11" × 17",
8-1/2" × 14", 8-1/2" × 13-1/2", 8-1/2" × 13-2/5", 8-1/2" × 13",
8-1/2" × 11", 8-1/2" × 11"R, 7-1/4 × 10-1/2"R, 8K, 16K, 16KR
Useable paper 60 g/m
2
to 220 g/m
2
(16 lbs. Bond to 80 lbs. Cover))
No. of trays 2
Tray capacity
(80g/m
2
(21 lbs.))
Upper tray: 200 sheets
Lower tray: 200 sheets
Required power
supply
Supplied from the machine
Dimensions 540 mm (W) × 760 mm (D) × 1276 mm (H)
(21-17/64" (W) × 29-59/64" (D) × 50-7/32" (H))
Weight Approx. 45 kg (99.2 lbs.)
Curl Correction Unit
Name Curl Correction Unit (MX-RB15)
Paper size Depends on feeder specications
Useable paper Depends on feeder specications
Dimensions 214 mm (W) × 760 mm (D) × 986 mm (H)
(8-7/16" (W) × 29-59/64" (D) × 38-13/16" (H))
Weight 16.4 kg (36.2 lbs)
Relay Unit
Name Relay Unit (MX-RB13) Relay Unit (MX-RB23)
Dimensions 214 mm (W) × 760 mm (D) ×
986 mm (H)
(8-7/16" (W) × 29-59/64" (D)
× 38-13/16" (H))
499 mm (W) × 718 mm (D) ×
210 mm (H)
(19-41/64" (W) × 28-17/64"
(D) × 8-17/64" (H))
Weight 14.5 kg (32.0 lbs) 5 kg (11.1 lbs)
Trimming Module
Name Trimming module (MX-TM10)
Useable size for
trimming module
A3W (12" × 18") A3, B4, A4R, 11" × 17", 8-1/2" × 14", 8-1/2"
× 13", 8-1/2" × 11"R, 8K
Max. no. of
sheets to be
trimmed
2 to 20 sheets (60 g/m
2
to 81.4 g/m
2
(16 lbs. Bond to 21 lbs.
Bond))
2 to 10 sheets (81.4 g/m
2
over to 105 g/m
2
(21 lbs. Bond over
to 28 lbs. Bond))
2 to 3 sheets (105 g/m
2
over to 220 g/m
2
(28 lbs. Bond over
to 80 lbs. Cover))
When plain paper trimmed. Including one front cover of 300
g/m
2
(110 lbs. Cover) or less.
Required power
supply
Supplied from saddle stitch nisher
Dimensions 251 mm (W) × 625 mm (D) × 403 mm (H)
(9-7/8" (W) × 24-15/32" (D) × 15-7/8" (H))
Weight Approx. 32 kg (70.6 lbs.)
Folding Unit
Name Folding unit (MX-FD10)
Folding types Z-Fold, C-Fold, Accordion Fold, Double Fold, Half Fold.
Useable size for
folding unit
Z-Fold: A3, B4, A4R, 11" × 17", 8-1/2" × 14", 8-1/2" × 11"R
C-Fold, Accordion Fold, Double Fold, Half Fold: A4R, 8-1/2" × 11"R
Useable paper 55 g/m
2
to 105 g/m
2
(16 lbs. Bond to 28 lbs. Bond))
Tray capacity
(80g/m
2
(21 lbs.))
C-Fold/Accordion Fold/Double Fold
60 mm (2-23/64") (Equivalent to 40 sheets. (Equivalent to 25
sheets for Double Fold))
Copies made in Z-Fold or Half Fold are output to the tray of
the nisher (large stacker) or saddle stitch nisher (large
stacker).
Required power
supply
Supplied from Finisher/Saddle stitch nisher
Dimensions 336 mm (W) × 793 mm (D) × 1050 mm (H)
(13-15/32" (W) × 31-7/32" (D) × 41-11/32" (H))
Weight Approx. 66 kg (145.5 lbs.)
Network Printer Specications
Type Built-in type
Continuous print
speed
Same as continuous copy speed
Resolution Data processing: 600 × 600 dpi, 1,200 × 1,200 dpi
Print: 600 × 600 dpi, equivalent to 9,600 dpi × 600 dpi,
1,200 × 1,200 dpi
Page description
language
Standard: PCL6 emulation, Adobe
®
PostScript
®
3™, XPS*
Compatible
protocols
TCP/IP (IPv4/IPv6), IPX/SPX, IPP, EtherTalk
Compatible OS Windows Server 2003, Windows Vista, Windows Server
2008, Windows 7, Windows 8, Windows Server 2012
Macintosh (Mac OS X 10.4, 10.5, 10.6, 10.7, 10.8, 10.9)
Internal fonts 80 fonts for PCL, 139 fonts for Adobe
®
PostScript
®
3™
Memory Machine system memory and hard disk
Interface
10BASE-T/100BASE-TX/1000BASE-T, USB 2.0 (high speed mode)
* XPS stands for XML Paper Specication. When equipped with the XPS
expansion kit (MX-PUX1). A memory (1GB) is required.
Fax Specications
Name Facsimile expansion kit (MX-FX11)
Useable lines General phone lines (PSTN), private branch exchange (PBX)
Connection
speed
Super G3: 33.6 kbps, G3: 14.4 kbps
Coding method MH, MR, MMR, JBIG
Connection
mode
Super G3 / G3
Original paper
sizes for
transmission
A3 (11" × 17") to A5 (5-1/2" × 8-1/2")
(Paper with a max. length of 1,000 mm can be transmitted
(one-sided only).)
Registered paper
size
A3 (11" × 17") to A5 (5-1/2" × 8-1/2")
Transmission
time
Approx. 2 seconds *
1
(A4 (8-1/2" × 11") Sharp standard
paper, normal characters, Super G3 (JBIG))
Approx. 6 seconds (G3 ECM)
Memory 1 GB
Notes Touch dial memory Max. of 2,000 entries (Including group
dialing for fax, scanner, and Internet
fax)
Entries per group Max. of 500 entries
Mass transmissions Max. of 500 recipients
* Complies with the 33.6 kbps transmission method for Super G3 facsimiles
standardized by the International Telecommunications Union (ITU-T). This is
the speed for when sending an A4 (8-1/2" × 11") size piece of paper of around
700 characters at standard image quality (8 × 3.85 chars/mm) in Hi-speed
mode (33.6 kbps). This is the transmission speed for image information only
and does not include time for transmission control. The actual time needed for
a transmission depends on the content of the text, type of receiving fax
machine, and telephone line conditions.
Network Scanner Specications
Type Colour scanner
Scan resolution
(main × vertical)
100 × 100 dpi, 150 × 150 dpi, 200 × 200 dpi, 300 × 300 dpi,
400 × 400 dpi, 600 × 600 dpi (push scan)
50 to 9,600 dpi *
1
(pull scan)
Scan speed
(A4 (8-1/2" × 11"))
Duplex Single Pass Feeder (DSPF)
B/W: 100 sheets/minute (200 × 200 dpi) (one-
sided), 200 pages/minute (200 × 200 dpi)
(two-sided)
Colour: 100 sheets/minute (200 × 200 dpi) (one-
sided), 200 pages/minute (200 × 200 dpi)
(two-sided)
• When in standard mode using Sharp standard paper (A4
(8-1/2" × 11") size with 6% coverage) and the auto colour
detector is turned off. The speed varies depending on the
data volume of the original.
