Sharp MX-M753 - Saddle Stitch Unit

8-17
TROUBLESHOOTING
Contents
SADDLE STITCH UNIT
1
Open the lower cover of the saddle
stitch finisher.
When an optional inserter is installed, open the front cover of
the inserter before opening the lower cover of the finisher.
2
Slide out the saddle stitch unit carefully
toward the front.
3
Remove the empty staple case.
4
While pushing down on lever (A), pull up
knob (B).
5
Remove any jammed staples, and then
return knob (B) to its original position.
Be sure to remove any strips of staples.
Do not touch the stapling area.
The stapler could injure you.
(A)
(B)
(B)
Jammed staples
