SECTION
TWO
Hardware
Specifications
1.
CPU
peripheral
For
the
CPU
of
the
MZ-5500
is
used
the
16-bit
CPU
(8086)
which
has
be~
me
the
main
trend
and
is
driven
by
5MHz
clock.
On
the
other
h~nd,
the
8086-11
is
adopted
for
the
MZ-5600
which
permits
8MHz/5MHz
selection
for
driving
clock.
In
the
5MHz
mode,
compatibility
is
obtained
for
the
real
time
processing
for
applica~ions
developed
on
the
MZ-5500.
Th
e
8086/8086-11
has
features
shown
in
Iable
1-1,
and
has
two modes
of
minimum
and
maximum
allowing
choice
of
pin
configuration
according
to
the
size
of
the
system
used.
lt
consists
of
the
execution
unit
(EU)
and
the
bus
interface
unit
(BIU);
the
B1U
manages
6-byte
command
queue
and
performs
address
generation,
and
the
EU
interprets
command
function.
Each
unit
operates
in
the
async
mode
and
enhances
high
throughput
by
the
use
of
the
pipe
line
processing.
It
is
possible
to
directly
access
the
memory up
to
Uili
,.
Using
AO
and
BHE
lines
of
the
8086,
da
ta
may
be
used
as
either
8-bit
or
16-bit
data.
Since
the
8086/8086-11
,
is
operated
under
the
maximum mode
for
the
MZ-SSOO/5600,
it
requires
the
8284
Clock
Generator
and
tUe
8288
Bus
Controller
in
order
to
operate
the
8086
as
the
CPU.
Not
only
the
8284
supplies
the
clock
(4.9152HHz)
to
the
8086,
but,
it
has
the
funetion
to
'
synchronize
the
READY
signal
generated
in
the
ready
control
circuit
with
the
clock
to
send
it
to
the
CPU.
Tlle
8288
is
the
bus
controller/driver
when
the
8086
is
operated
in
the
maximum mode.
Command
and
control
signals
are
decoded
from
the
status
output,
SO
-
S2,
from
the
CPU
to
issue
control
signal
to
the
1/0
device
and
the
memory.
As
a
ccprocessor
for
a
high
speed
numerical
operation
of
the
8086,
it
permits
direct
connection
of
the
8087
(MZ-5500),
8087-11
(MZ5600),
and
NDP
(option).
In
terms
of
software,
it
can
be
assumed
,
as
an
expansion
of
the
8086/8086-11
cornrnand
system.
AsTable
1-2
shows
its
execution
speed,
it
becomes
100
times
[aster
than
operated
with
only
the
8086/8086-11.
For
key
entry
of
the
MZ-SSOO/5600,
the
'
exclusive
80C49
subprocessor
is
used.
A
kcy
entry
is
transferred
by means
of
interrupt
only
when
there
was a
key
entry
so
that
it
decreases
the
burden
to
the
8086
and
allows
faster
system
operation.
The 80C49
is
also
used
for
handling
of
the
mouse
data.
Iable
1-1
Features
of
8086,
8086-11
(1)
16-bit
microprocessor
(2)
Rasic
commands: 90
(3)
Direct
acc~ssing
enabled
1MB
memory
space
(4)
14
x 16
bits
register
(5)
Arithmetical
operation
of
signed
or
unsigned
8
or
16
bits
data
including
mu1tiplication
and
division
(6)
SMHz,
single
clock
(8086)/8HHz
(8086-11)
(7)
Maskable
(INTR)
and
non-maskable
(NM1)
external
interrupt
input
(8)
Dual
mode
operation
(minimum/maximum)
(9)
N-channel
MOS
(JO)
Single
+5V
supply
(11)
40-pin
DIP
1'/
