Sharp Notevision PG-D45X3D User Manual

16
Quick Start
This section shows the basic operation (projector connecting with the computer). For details,
see the page described below for each step.
Setup and Projection
In this section, connection of the projector and the computer is explained using one example.
INPUT buttons
6
STANDBY button
8
KEYSTONE button
5
STANDBY/ON
button
3
8
5
KEYSTONE button
Focus ring
4
HEIGHT
ADJUST lever
4
3
ON button
6
COMPUTER button
5
Adjustment buttons
(P/R/O/Q)
5
Adjustment buttons
(P/R/O/Q)
Zoom ring
4
1. Place the projector facing a wall or a screen
B
P. 18
When connecting equipment other than a computer, see pages
22 and 23.
2. Connect the projector to the computer and plug the power
cord into the AC socket of the projector
BPP. 21, 25
On the projector On the remote control
3. Open the lens shutter fully and then turn the projector on
BP. 2 6
