PN-L803C/80TC3 SERVICE MENU/VARIOUS SETTING TOOL OPERATING PROCEDURES 4- 22
12-4. SYSTEM LOGS AND TAB
Logs are displayed with list format downside. Each item’s
meanings are below.
LOG’S MEANING
Header Meaning and remark
ID
The smaller the number, the newer
the log data.
Use [ID] to line up in the order of
operation.
Date
It displays date and time when
operation occurred. The icon is
displayed on left edge to stand out, if
“Kind” is “Abnormal State”.
Time elapsed from
Power Supply
It displays the operation time. (The
time after turning on the power of the
monitor.)
Kind
It displays the kind of log. Detail
information is described in “Log
Kind”.
Input
If “Kind” is “Operation” or “Abnormal
State”, it displays the input source of
main screen. If “Kind” is “Change
Signal”, it displays the input source
which signal is changed and displays
which screen (Main or Sub)’s signal
is changed in parenthesis. If “Kind” is
“Power Off Reason”, it displays
none.
Information
It displays information depending on
“Kind”.
Detail information is described in
“Log Kind”.
Parameter 1/2
It displays parameter. Detail
information is not open.
LOG KIND
Header Meaning and remark
Abnormal State
Log
It displays the log about abnormal
state, for example “Temperature
error”. Abnormal kind is
displayed in “Information”.
Change Power
State Log
It displays the log of power off. The
reason of power change is
displayed in “Information”.
Change Signal
Log
It displays the log changing signal.
The timing of new signal is
displayed in “Information” as
“[Width] x [Height] @ [Refresh
rate]” or “No Signal”.
Header Meaning and remark
Operation with IR
Remote/Key
It displays the log of
operations with IR remote
or button on body.
Operation record is
displayed in “Information”.
Operation by
RS-232C
Operation
It displays the log of
operation by RS-232C
command. The command
is displayed in
“Information”.
Extended Operation
by RS-232C
(Operation)
The sent command is
displayed in “Information”.
Operation by
Browser(Operation)
It displays the log of
operation by browser. The
command the occurred by
operation
(RS-223C/LAN command)
is displayed in
“Information”
Extended Operation
by Browser
Operation
Other Operation
Operation
It displays the log of
operation except above,
for example, power off by
schedule timer. Operation
kind is displayed in
“Information”.
Developer Info It displays the Information
for the developer.
