E-9
System connections General control
■ AC connection
Please ensure that the voltage marked on the rating
label, located on the rear panel, is the same as the
voltage in your area. Insert the end of the power
lead into the AC IN socket on the back of the unit.
Plug the other end of the cable into the wall socket.
■ To turn the power on or off
● Press the /FUNCTION to power ON.
● Press and hold the /FUNCTION 3 seconds to
power OFF.
Notes
I
n USB/Bluetooth
®
/LINE IN mode, when no operation
is
performed for 15 minutes, the unit will automatically
enter standby mode. To resume operation, press
the /FUNCTION.
■ Setting the function mode
To change the function, press the /FUNCTION
button to select the USB /Bluetooth
®
/LINE IN function.
■ Volume control
Rotate the VOLUME knob to increase or decrease
the volume.
Current volume level will be shown on the display.
■ Lighting mode
Press the LIGHT button repeatedly to select the
different lighting mode of LED indicator light on
the speaker. The display shows LEd1 to LEd7 and
LEd0 (Light OFF).
● “LEd1” Slow moving and slow color change
● “LEd2” Fast moving sync with the music and
slow color change
● “LEd3” Rainbow color sync with the music
● “LEd4” Circle light breathe and color change
sync with the music
● “LEd5” RGB color blinking Circle light sync with
the music
● “LEd6” One color blink with music and color
change
● “LEd7” White color blink
● ”LEd0” Light OFF
■ Bass and treble level control
● Rotate the TREBLE knob to adjust the treble.
● Rotate the BASS knob to adjust the bass.
■ SUPER BASS function
Press SUPER BASS button to switch the bass
mode on/off. The “B-ON” will be shown on the
display when the bass is switched on and “B-OF”
will be shown when off.
AC outlet
(AC 100 - 240V
~50/60 Hz)
CAUTION:
TO PREVENT ELECTRIC
SHOCK MATCH WIDE
BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
PS990_IM_EN.indd 9PS990_IM_EN.indd 9 7/11/23 12:42 PM7/11/23 12:42 PM
