GENERAL
Power source:
Output power:
Semiconductors:
Dimensions:
Weight:
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT,
PLEASE REFER TO THE
OPERATlON
MANUAL.
SPECIFICATIONS
TAPE RECORDER
ACllOV-127Vand220V-
240 V,
50160
Hz
DC
9V
(UM/SUM-2
or
RI4
type
x 6)
MPO; 7.2 W
(3.6W
+
3.6W)
(AC operation)
RMS;
4.6 W (2.3
W
+ 2.3 W)
(DC operation, 10% distortion)
PMPO; 14
W
(7
W
+ 7 W)
(AC operation)
5
ICS
1 Transistors
10 Diodes
2 LEDs
Width; 402 mm
(15-I
3/l
6”)
Height; 137 mm
(5-7/16”)
Depth; 81 mm (3-31’16”)
1.7 kg (3.75
Ibs.)
without batteries
Tape:
Compact cassette tape
Frequency range:
50 Hz
-
10,000 Hz
Signal/noise ratio:
36
dB
Input impedance:
External mic; 600 ohms
Output level and
loaded impedance:
Headphones; 8 ohms
-
32 ohms
RADIO
Frequency range:
AM; 526.5
kHz
-
1606.5
kHz
SW,;
2.3 MHz
-
7.3 MHz
SW
;
7.3 MHz
-
22 MHz
FM; 87.6 MHz
-
108
MHz
SPEAKERS
Speakers:
9 cm
(3-l/2”)
x
2
Specifications for this model are subject to change without
prior notice.
1.
Volume Control
2.
Balance Control
3. Tone Control
4. Function Selector Switch
5.
Pause Button
6. Stop/Eject Button
7. Fast Forward Button
8. Rewind Button
9. Play Button
10. Record Button
11. FM Mode Selector
12. Band Selector
NAMES
OF
PARTS
13. Tuning Control
14. Power Indicator
15. FM Stereo Indicator
16. Digital Tape Counter and Counter Reset Button
17. Cassette Compartment
18. Fine Tuning
19. Built-in Microphone
20. External Microphone Jacks
21.
FM/SW
Telescopic Rod Antenna
22. Headphones Jack
23. AC Power Supply Socket
24. Battery Compartment Lid
Figure 2-l FRONT PANEL
Figure 2-2 REAR PANEL
l
This unit is provided with a carring belt, but it is not depicted in the following Figures.
