MAIN PWB
NOTES ON SCHEMATIC DIAGRAM
l Resistor:
To differentiate the units of resistors, such symbol as K is
used: the symbol K means 1000 ohm and the resistor
without any symbol is ohm-type resistor.
0 Capacitor:
To indicate the unit of capacitor, a symbol P is used:
this symbol P means micro-micro-farad and the unit of
the capacitor without such a symbol is microfarad. As
to electrolytic capacitor, the expression “capacitance/
withstand voltage” is used.
l The indicated voltage in each section is the one measured
by Digital Multimeter between such a section and the
chassis with no signal given.
(
1: AM mode
Marking except for (
1: FM mode
l Schematic diagram and Wiring Side of P.W.Board for this
model are subject to change for improvement without prior
notice.
. Parts marked with “ A” ( -,‘) are important for main-
taining the safety of the set.
Be sure to replace these parts
with specified ones for maintaining the safety and per-
formance of the set.
