30
R-200BK
R-200BW
REF. NO. PART NO. DESCRIPTION Q'TY CODE
R42 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
R60-61 VRD-B12EF104J Resistor 100k ohm 1/4W 2 AA
R62-63 VRD-B12EF472J Resistor 4.7k ohm 1/4W 2 AA
R70 VRD-B12EF431J Resistor 430 ohm 1/4W 1 AA
R71 VRD-B12EF331J Resistor 330 ohm 1/4W 1 AA
R72 VRD-B12EF241J Resistor 240 ohm 1/4W 1 AA
R73 VRD-B12EF151J Resistor 150 ohm 1/4W 1 AA
R74 VRD-B12EF101J Resistor 100 ohm 1/4W 1 AA
RY1 RRLY-A110DRE0 Relay (OMIF-S-124LM) 1 AL
SP1 RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
SW1 RVR-BA018WRE0 Rotary encoder 1 AL
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
ZD1-2 VHEHZ12A1//-1 Zener diode (HZ12A1) 2 AA
ZD4-5 VHEHZ6C3///-1 Zener diode (HZ6C3) 2 AA
ZD6 VHEHZ4C3///-1 Zener diode (HZ4C3) 1 AA
3- 2 HPNLCB438WRR0 Control panel [R-200BK] 1 AV
3- 2 HPNLCB440WRR0 Control panel [R-200BW] 1 AV
3- 3 TCAUAA100WRR0 User caution label [R-200BK] 1 AC
3- 3 TCAUAA156WRR0 User caution label [R-200BW] 1 AF
3- 4 XEPSD30P08XS0 Screw; 3mm X 8mm 3 AA
OVEN PARTS
4- 1 PHOK-A105WRF0 Latch hook 1 AL
4- 2 LANGQA477WRW0 Light mount plate 1 AY
4- 3 PCUSUA502WRP0 Waterproof cushion 1 AD
4- 4 LBNDKA038WRP0 Capacitor holder 1 AF
4- 5 NFANJA029WRE0 Fan blade 1 AL
4- 6 PDUC-A694WRF0 Fan duct 1 AG
4- 7 ************* Oven cavity (Not replaceable part) 1--
4- 8 GLEGPA073WRF0 Leg 1 AD
4- 9 LANGTA318WRP0 Chassis support 1 AE
4-10 PCUSUA270WRP0 Cushion 1 AG
4-11 PCOVPA276WRE0 Waveguide cover 1 AM
4-12 PCOVPA342WRF0 B-cover Right 1 AH
4-13 PCOVPA343WRF0 B-cover Left 1 AH
4-14 PCUSUA443WRP0 Cushion 1 AE
4-15 PDUC-A700WRF0 Air separator 1 AN
4-16 PPACGA097WRE0 O-ring 1 AG
DOOR PARTS
5- 1 FDORFA321WRT0 Door panel 1 AT
5- 2 GWAKPA552WRF0 Door frame [R-200BK] 1 AY
5- 2 GWAKPA551WRF0 Door frame [R-200BW] 1 AY
5- 3 HPNL-A686WRR0 Door screen 1 AY
5- 4 LSTPPA175WRF0 Latch head 1 AE
5- 5 MSPRTA084WRE0 Latch spring 1 AB
5- 6 PSHEPA622WRE0 Sealer film 1 AG
5- 7 GCOVHA390WRF0 Choke cover 1 AK
5- 8 XCPSD40P08000 Screw : 4mm x 8mm 4 AA
MISCLANEOUS
6- 1 FROLPA085WRK0 Turntable support 1 AS
6- 2 NTNT-A094WRE0 Turntable 1 AN
6- 3 TINS-A644WRR0 Instruction book 1 AD
6- 4 TCAUAA145WRR0 Earth caution 2 AG
6- 5 FW-VZB655WRE0 Main wire harness 1 BA
6- 6 QW-QZA150WRE0 High voltage wire B 1 AF
6- 7 TCAUAA166WRR0 DHHS caution label 1 AC
6- 8 TCAUAA240WRR0 Screw caution 1 AC
6- 9 TCAUAA239WRR0 Monitor caution 1 AC
SCREWS AND WASHERS
7- 1 XFPSD40P08K00 Screw : 4mm x 8mm 5 AA
7- 2 LX-EZA042WRE0 Special screw 2 AB
7- 3 LX-WZA028WRE0 Special washer 1 AB
7- 4 LX-CZA030WRE0 Special screw 5 AA
7- 5 XHTSD40P08RV0 Screw : 4mm x 8mm 4 AA
7- 6 XHPSD30P06000 Screw : 3mm x 6mm 1 AA
7- 7 XOTSD40P12RV0 Screw : 4mm x 12mm 2 AA
7- 8 XOTSD40P12000 Screw : 4mm x 12mm 6 AA
7- 9 XOTSE40P08000 Screw : 4mm x 8mm [R-200BW] 4 AA
7- 9 XOTSF40P08000 Screw : 4mm x 8mm [R-200BK] 4 AA
7-10 LX-CZA071WRE0 Special screw (Torx tamper proof screw) 2 AC
∆
∆
∆
*
