Sharp R-200BK User Manual

29
R-200BK
R-200BW
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 QSW-MA131WRE0 Secondary interlock switch & door sensing switch 2 AG
1- 2 FFS-BA020WRK0 C/T fuse & monitor switch assembly 1 AP
1- 3 FACCDA040WRE0 Power supply cord 1 AS
1- 4 QSOCLA021WRE0 Oven lamp socket 1 AH
1- 5 FH-DZA082WRK0 High voltage rectifier 1 AQ
1- 6 RC-QZA193WRE0 High voltage capacitor 1 AW
1- 6 RC-QZA199WRE0 High voltage capacitor (Interchangeable) 1 AT
1- 7 RMOTEA338WRE0 Fan motor 1 AV
1- 7 RMOTEA355WRE0 Fan motor (Interchangeable) 1 AU
1- 8 RV-MZA226WRE0 Magnetron 1 BE
1- 8 RV-MZA282WRE0 Magnetron (Interchangeable) 1 BP
1- 9 RLMPTA030WRE0 Oven lamp 1 AF
1-10 RMOTDA186WRE0 Turntable motor 1 AW
1-10 RMOTDA211WRE0 Turntable motor (Interchangeable) 1 AS
1-11 RTHM-A078WRE0 Thermal cut-out 125˚C 1 AK
1-12 RTRN-A560WRE0 Power transformer 1 BK
CABINET PARTS
2- 1 GCABUA657WRP0 Outer case cabinet [R-200BK] 1 AX
2- 1 GCABUA659WRP0 Outer case cabinet [R-200BW] 1 AX
2- 2 GDAI-A304WRP0 Bottom plate 1 AU
2- 3 GLEGPA074WRE0 Foot 2 AC
CONTROL PANEL PARTS
3- 1 CPWBFA758WRK0 Timer unit assembly [R-200BK] 1 BM
3- 1 CPWBFA759WRK0 Timer unit assembly [R-200BW] 1 BM
3- 1-1 CPWBFA772WRK0 Control unit 1 BM
3- 1-1A QCNCMA430DRE0 3-pin connector (CN-A) 1 AG
3- 1-2 HPNLTA133WRE0 Timer sheet 1 AH
3- 1-3 JKNBKA597WRF0 Timer knob [R-200BK] 1 AF
3- 1-3 JKNBKA598WRF0 Timer knob [R-200BW] 1 AF
3- 1-4 LHLD-A184WRF0 LED holder 1 AH
C1 VCF2B62CA155K Capacitor 1.5 uF 160VAC 1 AG
C3 VCEAB31EW108M Capacitor 1000 uF 25V 1 AC
C4 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AB
C5 VCEAB31CW476M Capacitor 47 uF 16V 1 AA
C6 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AB
C7 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AH
C20 VCEAB31HW104M Capacitor 0.1 uF 50V 1 AB
C21 VCEAB31VW106M Capacitor 10 uF 35V 1 AB
C30 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AH
C60-61 VCKYD11CY103N Capacitor 0.01 uF 16V 2 AH
CF1 RCRS-A012DRE0 Ceramic resonator (CST4.00MGW) 1 AD
D1-4 VHD1N4005E61B Diode (1N4005E) 4 AE
D20 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D22 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D30 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D70-85 VHD1SS270A/-1 Diode (1SS270A) 16 AA
FUSE1 QFS-AA005DRE0 IC PROTECTOR 1 AE
I-1 RH-IZA860DRE0 LSI 1 AL
LD1-20 VHPLTL1CHE/-3 Light emitting diode (LED) 20 AD
Q1 VS2SC1740S/-3 Transistor (2SC1740S) 1 AB
Q2 VS2SA1267Y/-3 Transistor (2SA1267Y) 1 AA
Q20 VSDTC143ES/-3 Transistor (DTC143ES) 1 AB
Q21 VSDTA143ES/-3 Transistor (DTA143ES) 1 AB
Q40 VSDTC143ES/-3 Transistor (DTC143ES) 1 AB
Q70-73 VSDTA143ES/-3 Transistor (DTA143ES) 4 AB
R1-2 VRD-B12HF201J Resistor 200 ohm 1/2W 2 AB
R3 VRS-B13AA102J Resistor 1.0k ohm 1W 1 AA
R5 VRD-B12EF102J Resistor 1.0k ohm 1/4W 1 AA
R6 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R10 VRD-B12HF104J Resistor 100k ohm 1/2W 1 AA
R11 VRS-L63DA101J Resistor 100 ohm 2W 1 AD
R20-21 VRD-B12EF472J Resistor 4.7k ohm 1/4W 2 AA
R30 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R31 VRD-B12EF473J Resistor 47k ohm 1/4W 1 AA
R40 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R41 VRD-B12EF102J Resistor 1.0k ohm 1/4W 1 AA
*
*
*
*
∆
*
∆
*

Sharp R-200BK Specifications

General

Brand	Sharp
Model	R-200BK
Category	Microwave Oven
Language	English
