Sharp R-216(G) - Parts List

R-216(G)
R-216(IN)
R-216(W)
R-216(Y)
29
*
*
*
∆*
*
*
*
*
PA RTS LIST
ELECTRIC PARTS
C RC-QZA295WRZZ High voltage capacitor 1 AV
C RC-QZA218WRE0 High voltage capacitor (Interchangeable)for production use 1--
F1 QFS-CA027WRZZ Fuse T6.3A 1 AG
F2 QFS-IA004WRE0 High voltage fuse 6.3A 1 AK
FM RMOTEA403WRZZ Fan motor 1 AZ
FM RMOTEA340WRE0 Fan motor (Interchangeable) 1 AX
FM RMOTEA389WRE0 Fan motor (Interchangeable) for production use 1 AX
MG RV-MZA306WRZZ Magnetron 1 BL
OL RLMPTA083WRZZ Oven lamp 1 AM
SW1 QSW-MA085WRE0 Monitored latch switch 1 AF
SW1 QSW-MA137WRE0 Monitored latch switch (Interchangeable) 1 AH
SW2 QSW-MA086WRE0 Monitor switch 1 AF
SW2 QSW-MA138WRE0 Monitor switch (Interchangeable) 1 AH
SW3 QSW-MA085WRE0 2nd. interlock relay control switch 1 AF
SW3 QSW-MA137WRE0 2nd. interlock relay control switch (Interchangeable) 1 AH
T RTRN-A650WRZZ High voltage transformer 1 BQ
TC1 RTHM-A117WRE0 Thermal cut-out 95˚C (MG) 1 AK
TC1 RTHM-A079WRE0 Thermal cut-out 95˚C (MG) (Interchangeable) 1 AH
TC2 RTHM-A116WRE0 Thermal cut-out 125˚C (OVEN) 1 AK
TC2 RTHM-A078WRE0 Thermal cut-out 125˚C (OVEN) (Interchangeable) 1 AK
TTM RMOTDA173WRE0 Turntable motor 1 AX
TTM RMOTDA226WRE0 Turntable motor (Interchangeable) 1 AT
1- 1 QACC-A075WRE0 Power supply cord 1 AW
1- 2 FPWBFA347WRKZ
Noise filter 1AX
1- 3 FH-DZA103WRKZ High voltage rectifier 1 AS
1- 3 FH-DZA082WRK0 High voltage rectifier (Interchangeable) 1 AQ
1- 3 FH-DZA087WRK0 High voltage rectifier (Interchangeable) 1 AQ
CABINET PARTS
2- 1 GCABUA696WRP0 Outer case cabinet [R-216(W)] 1 AX
2- 1 GCABUA851WRPZ Outer case cabinet [R-216(IN)] 1 BC
2- 1 GCABUA853WRPZ Outer case cabinet [R-216(G)] 1 BC
2- 1 GCABUA855WRPZ Outer case cabinet [R-216(Y)] 1 BC
2- 2 GDAI-A304WRW0 Bottom plate 1 AF
2- 3 GLEGPA074WRE0 Foot 2 AC
CONTROL PANEL PARTS
3- 1 DPWBFC264WRUZ Control unit 1 BG
3- 1A QCNCMA430DRE0 3-pin connector (CN-A) 1 AG
3- 1B QCNCMA410DRE0 2-pin connector (CN-B) 1 AB
C1 VCEAB31VW108M Capacitor 1000 uF 35V 1 AF
C2 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C3 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C4 VCEAB31CW476M Capacitor 47 uF 16V 1 AA
C5-6 RC-KZA087DRE0 Capacitor 0.1 uF 50V 2 AA
C10 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C11 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C20 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C21 VCEAB31VW106M Capacitor 10 uF 35V 1 AA
C30 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C60-61 VCKYD11CY103N Capacitor 0.01 uF 16V 2 AA
CF1 RCRS-A012DRE0 Ceramic resonator (CST4.00MGW) 1 AD
D1-4 RH-DZA006PRE0 Diode (1N4002E) 4 AD
D20-22 VHD1SS270A/-1 Diode (1SS270ATA) 3 AA
D30 VHD1SS270A/-1 Diode (1SS270ATA) 1 AA
IC-1 RH-IXA157DRZZ LSI 1 AT
LD1-24 VHPLTL1CHE/-3 Light emitting diode (LED) 24 AD
LD30-34 VHPLTL1CHE/-3 Light emitting diode (LED) 5 AD
Q1 VS2SB1238//-3 Transistor (2SB1238) 1 AA
Q2 VSKRA105M//-3 Transistor (KRA105M) 1 AB
Q10 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q20 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q21 VSKRC243M//-3 Transistor (KRC243M) 1 AB
Q22 VSKRA222M//-3 Transistor (KRA222M) 1 AB
Q24 VS2SB1238//-3 Transistor (2SB1238) 1 AA
Q40 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q50-53 VSKRA222M//-3 Transistor (KRA222M) 4 AB
R1 VRS-L63DA101J Resistor 100 ohm 2W 1 AD
R2 VRD-B12HF202J Resistor 2k ohm 1/2W 1 AB
R3 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R10 VRD-B12HF102J Resistor 1k ohm 1/2W 1 AA
R11 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
