R-2197
33
∆
∆
∆
∆
∆
∆
∆
∆
∆
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ZD2 VHEHZ4A2///-1 Zener diode (HZ4A2) 1 AA
3- 2 FPNLCB403WRK0 Control panel frame with key unit 1 BB
3- 2-1 FUNTKA899WRE0 Key unit 1 AV
3- 2-2 GCOVAA260WRP0 C/P case 1 BA
3- 2-3 GMADIA109WRF0 Display window 1 AE
3- 3 XEPSD30P08XS0 Screw; 3mm x 8mm 6 AA
OVEN PARTS
4- 1 FGLSPA062WRE0 Ceramic shelf BL
4- 2 DOVN-A514WRY0 Oven cavity 1 BU
4- 3 MLEVPA227WRF0 Latch switch lever A 1 AF
4- 4 MLEVPA228WRF0 Latch switch lever B 1 AF
4- 5 MLEVPA229WRF0 Latch switch lever C 1 AF
4- 6 MSPRCA108WRE0 Latch lever spring 3 AC
4- 7 MSPRTA191WRE0 Switch lever B spring 1 AC
4- 8 PHOK-A107WRF0 Latch hook 1 AL
4- 9 FDUC-A341WRY0 Steam duct sub assembly 1 BL
4-10 PSKR-A351WRP0 Steam guide 1 AY
4-11 LBNDKA139WRW0 HV capacitor holder 1 AR
4-12 NFANJA029WRE0 Fan blade 1 AK
4-13 PDUC-A697WRF0 Fan duct 1 AM
4-14 FPLT-A007WRY0 Stirrer antenna assembly 1 BB
4-15 PCUSUA507WRP0 Cushion 1 AC
4-16 PCUSGA378WRP0 Cushion 1 AL
4-17 PSPA-A112WRE0 Mica washer 1 AC
4-18 LANGFA187WRP0 Chassis support 1 AL
4-19 NSFTPA033WRF0 Antenna motor shaft 1 AK
4-20 PSKR-A359WRW0 Air guide 1 AM
4-21 PSKR-A349WRP0 Steam duct barrier 1 AF
4-22 PFILWA060WRP0 Lamp filter 1 AD
4-23 PDUC-A722WRF0 Air intake duct 1 AF
4-24 PCUSGA249WRP0 Cushion 1 AA
4-25 PCUSUA235WRP0 Cushion 1 AE
4-26 PCUSUA511WRP0 Cushion 2 AC
4-27 PCUSUA329WRP0 Cushion 1 AC
4-28 PCUSUA514WRP0 Cushion 1 AB
4-29 PPACGA073WRE0 Cushion 1 AP
4-30 PCUSUA515WRP0 Cushion 1 AD
4-31 PSHEPA668WRE0 Cover 1 AK
4-32 PCLICA034WRE0 Hand clip 3 AD
DOOR PARTS
5- 1 FDORFA322WRT0 Door panel assembly 1 AZ
5- 2 PSHEPA649WRE0 Sealer film 1 AB
5- 3 FANGKA206WRY0 Latch angle assembly 1 AW
5- 4 FCOV-A004WRK0 Door case assembly 1 BG
5-4-1 LSTPPA180WRF0 Glass stopper R 1 AK
5-4-2 LSTPPA182WRF0 Glass stopper U 1 AN
5-4-3 PGLSPA522WRE0 Front door glass 1 AQ
5-4-4 XCPSD40P08000 Screw : 4mm x 8mm 6 AA
5- 5 GWAKPA580WRM0 Door handle 1 AQ
5- 6 JHNDMA040WRW0 Handle lever 1 AN
5- 7 LANGKA874WRW0 Latch lever 1 AR
5- 8 LSTPPA181WRF0 Latch head 2 AL
5- 9 MSPRTA190WRE0 Latch spring 1 AD
5-10 PCUSUA506WRP0 Cushion 1 AC
5-11 XCPSD40P06000 Screw : 4mm x 6mm 1 AA
5-12 LSUB-A083WRE0 Sealed plate A 2 AF
5-13 LSUB-A084WRE0 Sealed plate B 2 AE
5-14 LSUB-A085WRE0 Sealed plate C 2 AE
5-15 PCUSUA505WRP0 Cushion 1 AC
5-16 XCPSD40P08000 Screw : 4mm x 8mm 4 AA
5-17 GCOVHA395WRF0 Choke cover 1 AK
5-18 HBDGCA086WRE0 Door badge 1 AF
5-19 XEPSD40P25K00 Screw : 4mm x 25mm 2 AB
5-20 PCUSUA508WRP0 Cushion 1 AC
5-21 PCUSGA514WRP0 Cushion 1 AG
MISCELLANEOUS
6- 1 TINSEA774WRR0 Instruction book 1 AH
6- 2 FW-VZB703WRE0 Main wire harness 1 AY
6- 3 PZETEA076WRE0 Switch insulator 1 AC
6- 4 TCAUHA214WRR0 K caution label 1 AC
6- 5 TSPCNC671WRR0 Rating label 1 AD
6- 6 TLABMA585WRR0 Menu sticker 1 AG
