Sharp R-2197 - Parts List

R-2197
32
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
*
*
∆
*
*
ELECTRIC PARTS
1- 1 QSW-MA086WRE0 Monitor switch 1 AF
1- 2 QSW-MA085WRE0 Stop switch 1 AF
1- 3 QSW-MA095WRE0 1st. latch switch and 2nd. latch switch 2 AF
1- 4 QACC-A045WRE0 Power supply cord 1 AP
1- 5 FH-DZA086WRK0 High voltage rectifier assembly 1 AT
1- 6 RC-QZA247WRE0 High voltage capacitor 1 BE
1- 7 RMOTEA378WRE0 Fan motor 1 AU
1- 8 RR-WZA022WRE0 Monitor resistor 0.8 ohm 20 W 1 AK
1- 9 QSOCLA022WRE0 Oven lamp socket 1 AG
1-10 RLMPTA069WRE0 Oven lamp 1 AK
1-11 RMOTDA234WRE0 Antenna motor 1 AR
1-12 RTHM-A080WRE0 Thermal cut-out 145 deg. (MAG) 1 AP
1-13 RTHM-A096WRE0 Thermal cut-out 125 deg. (OVEN) 1 AK
1-14 RTRN-A574WRE0 High voltage transformer 1 BQ
1-15 RV-MZA197WRE0 Magnetron 1 BN
1-16 QFS-IA002WRE0 High voltage fuse 1 AQ
1-17 QFS-CQ001YBE0 Fuse 10A 1 AE
1-18 FPWBFA325WRK0 Noise filter 1 AT
CABINET PARTS
2- 1 GCABUA672WRP0 Outer case cabinet 1 BH
2- 2 GDAI-A318WRW0 Base plate 1 AV
2- 3 GCOVHA406WRW0 Base plate cover 1 AQ
2- 4 GLEGPA074WRE0 Foot 2 AC
2- 5 GLEGPA076WRF0 Leg 1 AF
CONTROL PANEL PARTS
3- 1 CPWBFA818WRK0 Control unit 1 BK
3- 1A QCNCMA234DRE0 3-pin connector (A) 1 AC
3- 1B QCNCMA275DRE0 2-pin connector (B) 1 AB
3- 1C QCNCWA057DRE0 12-pin connector (G) 1 AF
C1 VCEAB51EW228M Capacitor 2200 uF 25V 1 AE
C2 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C3 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C4 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C5 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C6 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C7 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C8-9 RC-KZA087DRE0 Capacitor 0.1 uF 50V 2 AA
C20 VCEAB31HW104M Capacitor 0.1 uF 50V 1 AM
C21 VCEAB31EW106M Capacitor 10 uF 25V 1 AA
C30 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C31 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C70 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
CF1 RCRS-A012DRE0 Ceramic resonator CST4.00MGW 1 AD
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D20-21 VHD1SS270A/-1 Diode (1SS270A) 2 AA
D23 VHD11ES1///-1 Diode (11ES1) 1 AB
D70 VHD1SS270A/-1 Diode (1SS270A) 1 AA
IC1 RH-IZA897DRE0 LSI 1 AV
IC2 RH-IZA521DRE0 IC (X24C02P) 1 AL
IC3 RIC--A025BDE0 IC (KID65004AP) 1 AE
LED1 VHPSL3966T/1B Light emitting diode 1 AS
Q1 RIC--A022BDE0 IC (KIA7805P1) 1 AE
Q2 VSDTA123ES/-3 Transistor (DTA123ES) 1 AA
Q3 VSDTC143ES/-3 Transistor (DTC143ES) 1 AB
Q20 VSDTB143ES/-3 Transistor (DTB143ES) 1 AC
Q21 VSDTC143ES/-3 Transistor (DTC143ES) 1 AB
Q22 VSDTD143ES/-3 Transistor (DTD143ES) 2 AC
R3-5 VRD-B12EF472J Resistor 4.7k ohm 1/4W 3 AA
R30 VRD-B12EF101J Resistor 100 ohm 1/4W 1 AA
R31 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R32 VRD-B12EF272J Resistor 2.7k ohm 1/4W 1 AA
R33 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R40 VRD-B12EF272J Resistor 2.7k ohm 1/4W 1 AA
R50-58 VRD-B12EF101J Resistor 100 ohm 1/4W 9 AA
R70-71 VRD-B12EF472J Resistor 4.7 ohm 1/4W 2 AA
R80-88 VRD-B12EF472J Resistor 4.7 ohm 1/4W 9 AA
RY2 RRLY-A101DRE0 Relay (VRB12) 1 AL
RY3 RRLY-A094DRE0 Relay (OMIF-S-112LM) 1 AN
SP1 RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
T1 RTRNPA131DRE0 Touch control transformer 1 AR
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
