Sharp R-231F Service Manual

R-231F
6
SERVICING
WARNING TO SERVICE PERSONNEL
Microwave ovens contain circuitry capable of producing very high voltage and current, contact with any part of the
high voltage circuit will result in electrocution. High voltage capacitor, Power transformer, Magnetron, High voltage
rectifier assembly, High voltage fuse, High voltage harness.
REMEMBER TO CHECK 3D
1) Disconnect the supply.
2) Door opened, and wedged open.
3) Discharge the high voltage capacitor.
WARNING: AGAINST THE CHARGE OF THE
HIGH-VOLTAGE CAPACITOR
The high-voltage capacitor remains charged about
60 seconds after the oven has been switched off.
Wait for 60 seconds and then short-circuit the
connection of the high-voltage capacitor (that is, of
the connecting lead of the high-voltage rectifier)
against the chassis with the use of an insulated
screwdriver.
Sharp recommend that wherever possible fault-finding
is carried out with the supply disconnected. It may, in
some cases, be necessary to connect the supply after
the outer case has been removed, in this event carry out
3D checks and then disconnect the leads to the primary
of the power transformer. Ensure that these leads
remain isolated from other components and the oven
chassis. (Use insulation tape if necessary.) When the
testing is completed, carry out 3D checks and recon-
nect the leads to the primary of the power transformer.
REMEMBER TO CHECK 4R
1) Reconnect all leads removed from components
during testing.
2) Replace the outer case (cabinet).
3) Reconnect the supply.
4) Run the oven. Check all functions.
Microwave ovens should not be run empty. To test for
the presence of microwave energy within a cavity,
place a cup of cold water on the oven turntable, close
the door and set the power level to HIGH. And set the
microwave timer for two (2) minutes. When the two
minutes has elapsed (timer at zero) carefully check
that the water is now hot. If the water remains cold,
carry out 3D checks and re-examine the connections to
the component being tested.
When all service work is completed and the oven is fully assembled, the microwave power output should be
checked and microwave leakage test should be carried out.
IMPORTANT: If the oven becomes inoperative because
of a blown fuse T6.3A in the 1st. latch
switch - 2nd. interlock relay - monitor
switch circuit, check the 1st. latch switch,
2nd. interlock relay control switch, 2nd.
interlock relay and monitor switch before
replacing the fuse T6.3A.
When troubleshooting the microwave oven, it is helpful
to follow the Sequence of Operation in performing the
checks. Many of the possible causes of trouble will re-
quire that a specific test be performed. These tests are
given a procedure letter which will be found in the "Test
Procedure"section.
TROUBLESHOOTING GUIDE

Sharp R-231F Specifications

Power

AC power required	1.21 kW
output power	800 W
microwave frequency	2450 MHz

Weight and Dimensions

outside width	460 mm
outside height	275 mm
outside depth	353 mm
cavity width	322 mm
cavity height	212 mm
cavity depth	336 mm
weight	12 kg
