Sharp R-2397 - Parts List

34
R-2397
PARTS LIST
*
*
∆*
*
ELECTRIC PARTS
1- 1 FH-HZA050WRE0 Magnetron thermistor 1 AP
1- 2 QSOCLA011WRE0 Oven lamp socket 1 AH
1- 3 FH-HZA049WRE0 Intake thermistor 1 AL
1- 4 FPWBFA296WRE0 Noise filter 1 AW
1- 5 QFSHDA019WRE0 Fuse holder 3 AH
1- 6 QACCVA066WRE0 Power supply cord for European continental use 1 BG
1- 7 DH-HZA009WRK0 Exhaust thermistor 1 AP
1- 8 FW-QZA106WRK0 High voltage rectifier assembly 1 BB
1- 9 RTHM-A091WRE0 Oven thermal cut-out 115˚C 1 AK
1-10 QSW-MA085WRE0 Stop switch 1 AF
1-11 QSW-MA086WRE0 Monitor switch 1 AF
1-12 QSW-MA095WRE0 1st. latch switch 1 AF
1-13 QSW-MA095WRE0 2nd. latch switch 1 AF
1-14 QSW-MA095WRE0 3rd. latch switch 1 AF
1-15 RC-QZA165WRE0 High voltage capacitor 2 AX
1-16 RLMPTA028WRE0 Oven lamp 1 AK
1-17 RMOTDA209WRE0 Stirrer motor 2 AR
1-18 RTHM-A037WRE0 Magnetron thermal cut-out 145˚C 1 AG
1-19 RTHM-A057WRE0 Magnetron thermal cut-out 145˚C 1 AG
1-20 RV-MZA239WRE0 Magnetron 2 BL
1-21 QFS-CA017WRE0 Weak point A017 1 AF
1-22 QFS-CA007WRE0 Fuse F6.3A 1 AD
1-23 QFS-CA018WRE0 Weak point A018 2 AD
1-24 RR-WZA020WRE0 Monitor resistor 4.3 Ω 20W 1 AF
1-25 FMOTEA309WRK0 Blower motor 1 BH
1-26 RTHM-A058WRE0 Thermal cut-out 115˚C 1 AG
1-27 RTRN-A459WRE0 High voltage transformer 2 BP
1-28 RFIL-A004WRE0 Ferrite clamp R 2 AM
1-29 RFIL-A002WRE0 Ferrite clamp 2 AP
CABINET PARTS
2- 1 FDAI-A183WRW0 Base plate assembly 1 BC
2- 2 PSHEGA006WRE0 Rubber sheet A 2 AF
2- 3 PSHEGA007WRE0 Rubber sheet B 2 AE
2- 4 GCOVAA250WRW0 Rear cabinet 1 AX
2- 5 FFTASA064WRY0 Oven lamp access cover assembly 1 AN
2-5-1 PCUSU0407WRP0 Cushion 1 AA
2-5-2 PREFHA059WRP0 Lamp reflector 1 AF
2-6 GCABUA523WRP0 Outer case cabinet 1 BA
2-7 PZETEA071WRP0 Cabinet insulation sheet 1 AF
CONTROL PANEL PARTS
3- 1 DPWBFB382WRU0 Control unit 1 BQ
3- 1A QCNCMA308DRE0 4-pin connector (A) 1 AC
3- 1B QCNCMA312DRE0 3-pin connector (B) 1 AB
3- 1C QCNCMA145DRE0 3-pin connector (D) 1 AB
3- 1D QCNCWA030DRE0 12-pin connector (G) 1 AF
3- 1E QCNCMA039DRE0 3-pin connector (H) 1 AB
3- 1F QLUG-A002PRE0 Tab terminal (TAB1-4) 4 AB
3- 1G RV-KXA053DRE0 Fluorescent display tube 1 AW
3- 1H PCUSGA359WRP0 Cushion 2 AC
C1 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C2 RC-EZA192DRE0 Capacitor 1000 uF 35V 1 AD
C3 VCEAB31HW335M Capacitor 3.3 uF 50V 1 AA
C4 VCKYB11EX103N Capacitor 0.01 uF 25V 1 AA
C5 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C6-7 VCKYD11CY103N Capacitor 0.01 uF 16V 2 AA
C8 VCEAB31CW107M Capacitor 100 uF 16V 1 AB
C9 VCEAB31EW226M Capacitor 22 uF 25V 1 AA
C20 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C21 VCKYF31HF103Z Capacitor 0.01 uF 50V 1 AA
C22 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C30 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C61-62 VCEAB31EW226M Capacitor 22 uF 25V 2 AA
C70 VCKYF31HF103Z Capacitor 0.01 uF 50V 1 AA
C71 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C72 VCKYB11EX103N Capacitor 0.01 uF 25V 1 AA
C74 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
