35
R-2397
C80 VCEAB31HW104M Capacitor 0.1 uF 50V 1 AM
C81 VCEAB31HW225M Capacitor 2.2 uF 50V 1 AA
C82 VCEAB31HW105M Capacitor 1.0 uF 50V 1 AA
C200 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
CF1 RCRS-A010DRE0 Ceramic resonator CST4.00MGW 1 AD
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D5 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D6-7 VHD11ES1///-1 Diode (11ES1) 2 AB
D61-64 VHD1SS270A/-1 Diode (1SS270A) 4 AA
D70 VHD11ES1///-1 Diode (11ES1) 1 AB
D71 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D81 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D83-84 VHD1SS270A/-1 Diode (1SS270A) 2 AA
D93-97 VHD1SS270A/-1 Diode (1SS270A) 5 AA
IC1 RH-IZA646DRE0 LSI 1 AX
IC2 RH-IZA571DRE0 IC (AT24C04) 1 AP
Q1 VS2SB953-PQ-4 Transistor (2SB953) 1 AG
Q2 VS2SA1561TL-3 Transistor (2SA1561TL) 1 AA
Q20 RH-TZA037CBE0 Transistor (KRA101M) 1 AA
Q40 RH-TZA037CBE0 Transistor (KRA101M) 1 AA
Q41 VS2SB1238//-3 Transistor (2SB1238) 1 AA
Q80 VSDTA114YS/-3 Transistor (DTA114YS) 1 AB
Q81 VSDTD143ES/-3 Transistor (DTD143ES) 1 AC
Q83-84 VSDTB143ES/-3 Transistor (DTB143ES) 2 AC
R1 VRD-B12EF182J Resistor 1.8k ohm 1/4W 1 AA
R3 VRD-B12HF561J Resistor 560 ohm 1/2W 1 AA
R4 VRD-B12EF102J Resistor 1.0k ohm 1/4W 1 AA
R5 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R6 VRD-B12HF150J Resistor 15 ohm 1/2W 1 AA
R20 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R31 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R32 VRD-B12EF272J Resistor 2.7k ohm 1/4W 1 AA
R33 VRD-B12EF103J Resistor 10k ohm 1/4W 1 AA
R40 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
R41 VRD-B12EF203J Resistor 20k ohm 1/4W 1 AA
R42 VRD-B12EF393J Resistor 39k ohm 1/4W 1 AA
R43 VRD-B12EF103J Resistor 10k ohm 1/4W 1 AA
R50 VRD-B12EF182J Resistor 1.8k ohm 1/4W 1 AA
R61-62 VRN-B12EK152F Resistor 1.5k ohm(F) 1/4W 2 AA
R63-64 VRD-B12EF102J Resistor 1.0k ohm 1/4W 2 AA
R65-66 VRD-B12EF304J Resistor 300k ohm 1/4W 2 AA
R67-68 VRD-B12EF473J Resistor 47k ohm 1/4W 2 AA
R70 VRD-B12EF101J Resistor 100 ohm 1/4W 1 AA
R71 VRD-B12EF303J Resistor 30k ohm 1/4W 1 AA
R72 VRD-B12EF112J Resistor 1.1k ohm 1/4W 1 AA
R73 VRD-B12EF203J Resistor 20k ohm 1/4W 1 AA
R74 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
R79 VRD-B12EF473J Resistor 47k ohm 1/4W 1 AA
R80 VRD-B12EF471J Resistor 470 ohm 1/4W 1 AA
R83-84 VRD-B12HF390J Resistor 39 ohm 1/2W 2 AA
R93-101 VRD-B12EF153J Resistor 15k ohm 1/4W 9 AA
R200 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R201 VRD-B12EF682J Resistor 6.8k ohm 1/4W 1 AA
R300 VRD-B12EF105J Resistor 1.0M ohm 1/4W 1 AA
(J2) VRD-B12EF822J Resistor 8.2k ohm 1/4W 1 AB
(J3) VRD-B12EF363J Resistor 36k ohm 1/4W 1 AA
RY1 RRLY-A078DRE0 Relay (OJ-SH-118LM) 1 AG
RY3-4 RRLY-A059DRE0 Relay (VS14MB-NR-SH6) 2 AK
SP1 RALM-A003DRE0 Buzzer (PS3025P02) 1 AG
T1 RTRNPA080DRE0 Touch control transformer 1 AU
CT1-2 RTRN-A060DRE0 Current transformer 2 AH
VRS1 RH-VZA010DRE0 Varistor (TNR15G471K) 1 AE
ZD1 VHEHZ12C1//-1 Zener diode (HZ12C1) 1 AA
ZD2 VHEHZ4C3///-1 Zener diode (HZ4C-3) 1 AA
3- 2 FPNLCB159WRK0 Control panel frame with key unit assembly 1 AZ
3- 2-1 FUNTKA775WRE0 Key unit 1 AU
3- 2-2 HDECAA195WRP0 Decoration metal fittings 1 AP
3- 2-3 PCUSUA451WRP0 Cushion 1 AB
3- 3 LANGTA243WRW0 Control panel mounting angle 1 AF
3- 4 XEPSD30P10XS0 Screw; control unit mounting 6 AA
3- 5 XEPSD40P12000 Screw; control panel mounting angle mounting 1 AA
3- 6 XFTSD40P08K00 Screw; decoration panel mounting for earth 1 AB
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
