36
R-2397
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
∆
∆
∆
∆
3- 7 PCUSGA380WRP0 Cushion 1 AA
OVEN PARTS
4- 1 PCUSUA265WRP0 Cushion 1 AA
4- 2 PDUC-A565WRW0 Exhaust duct 1 AZ
4- 3 FOVN-A336WRY0 Oven cavity 1 BR
4- 4 PFILWA053WRP0 Oven light screen 1 AE
4- 5 MLEVPA153WRF0 Switch lever A 1 AC
4- 6 MLEVPA154WRF0 Switch lever B 1 AC
4- 7 MLEVPA155WRF0 Switch lever C 1 AC
4- 8 MSPRCA075WRE0 Switch spring A 1 AB
4- 9 MSPRCA076WRE0 Switch spring B 2 AB
4-10 PHOK-A081WRF0 Latch hook 1 AP
4-11 PZETEA047WRP0 Switch insulator 1 AC
4-12 PDUC-A566WRF0 Mg air guide 1 AN
4-13 PDUC-A567WRF0 Mg air guide cover 1 AN
4-14 FGLSPA021WRY0 Ceramic shelf 1 BD
4-15 FPLT-A006WRY0 Stirrer antenna upper assembly 1 AT
4-16 FPLT-A005WRY0 Stirrer antenna lower assembly 1 AY
4-17 LANGKA762WRP0 Partition angle R 1 AE
4-18 LANGQA370WRP0 Oven lamp mounting plate 1 AD
4-19 LBNDKA075WRP0 Capacitor holder 1 AD
4-20 PGIDHA054WRW0 Water-proof cover 1 AF
4-21 NSFTPA031WRF0 Antenna motor shaft 2 AH
4-22 PCOVPA310WRF0 Splash cover 1 AZ
4-23 PCUSGA405WRP0 Cushion 1 AF
4-24 PCUSGA409WRP0 Cushion 2 AE
4-25 PCUSUA413WRP0 Cushion 1 AG
4-26 PCUSUA415WRP0 Cushion 2 AC
4-27 PCUSUA416WRP0 Cushion 4 AC
4-28 PDUC-A607WRW0 Mg exhaust duct 1 AP
4-29 PCUSUA414WRP0 Cushion 1 AD
4-30 LANGQA251WRW0 Noise filter angle 1 AF
4-31 LANGQ0382WRM0 Earth angle 1 AB
4-32 LANGFA172WRP0 Chassis support 1 AH
4-33 LBSHCA012WRE0 Cord bushing 1 AD
4-34 PCUSGA441WRP0 Cushion 1 AL
4-35 FFIL-A003WRK0 Air intake filter assembly 1 AV
4-36 HDECEA001WRP0 Decoration sash 1 AR
4-37 HDECQA146WRM0 Corner cap left 1 AE
4-38 HDECQA147WRM0 Corner cap right 1 AE
4-39 LANGKA679WRM0 Fixing angle s 1 AD
4-40 MHNG-A215WRM0 Upper oven hinge 1 AG
4-41 MHNG-A216WRM0 Lower oven hinge 1 AG
4-42 PCUSGA275WRP0 BLM cushion 1 AB
4-43 PCUSUA417WRP0 Cushion 1 AB
4-44 MSPRCA101WRE0 Switch spring C 1 AC
4-45 PCUSUA458WRP0 V/P cushion 1 AB
4-46 LANGQA440WRM0 Earth angle 1 AE
4-47 PCUSGA289WRP0 Cushion 1 AB
4-48 PCUSUA268WRP0 Cushion 1 AA
4-49 PZETEA073WRP0 Insulator sheet B 1 AF
4-50 PCUSUA448WRP0 Cushion 1 AC
4-51 PCUSGA442WRP0 Cushion 1 AD
4-52 PCUSGA443WRP0 Cushion 1 AC
4-53 PCUSUA447WRP0 Cushion 1 AC
4-54 PCUSGA045WRP0 Cushion 1 AA
DOOR PARTS
5 DDORFA746WRK0 Door assembly 1 BP
5- 1 FDORFA289WRT0 Door panel assembly 1 BH
5- 2 GCOVAA242WRY0 Door case 1 BD
5- 3 FHNDMA011WRY0 Door release lever assembly 1 AP
5- 4 GCOVHA350WRF0 Choke cover 1 AR
5- 5 JHNDPA169WRM0 Door handle 1 AU
5- 6 LANGKA766WRP0 Outside window fixing plate 2 AF
5- 7 PCUSGA430WRP0 Cushion 2 AM
5- 8 PGLSPA457WRE0 Door glass 1 AV
5- 9 PPACGA142WRP0 Door case packing 2 AF
5-10 PSHEPA520WRE0 Sealer film 1 AH
5-11 PSPA-A102WRE0 Door screen spacer 2 AE
5-12 XFPSD40P08K00 Screw : 4mm x 8mm 3 AA
