3
OVEN AND ACCESSORIES
ENGLISH
3
1 Control panel
2 Oven lamp
3 Door opening handle
4 Waveguide cover
5 Seal packing
6 Oven cavity
7 Door seals and sealing surfaces
8 Ventilation openings
9 Outer cabinet
10 Power cord
8
10
ACCESSORIES:
Check to make sure the following accessories are
provided:
(11) Turntable (12) Roller stay (13) Seal packing
• Place the roller stay in the seal packing on the
floor of the cavity.
• Then place the turntable on the roller stay.
• To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your dealer
or SHARP authorised service agent.
11
12
13
1
2
7 6 5 4
9
To Next Page
