R-305EW
*
*
*
∆
*
∆
*
*
∆
∆
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 QSW-MA147WRZZ 2nd interlock switch / door sensing switch 2 AG
1- 1 QSW-MA137WRE0
2nd interlock switch/door sensing switch (Interchangeable)
2AH
1- 2 QFSHDA009WRE0 Fuse holder 1 AH
1- 3 FFS-BA021WRK0
Monitor fuse 20A and monitor switch (V-16G-2C25) assembly
1AL
1- 3 FFS-BA023WRK0 " " (AM51620C53Y1) assembly (Interchangeable) 1 AS
1- 4 RTHM-A116WRE0 Thermal cut-out 125 deg. 1 AK
1- 4 RTHM-A078WRE0 Thermal cut-out 125 deg. (Interchangeable) 1 AL
1- 5 FACCDA082WRE0 Power supply cord 1 AV
1- 5 FACCDA081WRE0 Power supply cord (Interchangeable) 1 AP
1- 6 FH-DZA092WRK0 High voltage rectifier assembly 1 AK
1- 7 RC-QZA286WRZZ High voltage capacitor 1 AV
1- 7 RC-QZA211WRE0 High voltage capacitor (Interchangeable) 1 AV
1- 8 RV-MZA288WRE0 Magnetron 1 BK
1- 8 RV-MZA291WRE0 Magnetron (Interchangeable) 1 BH
1- 9 RMOTEA383WRE0 Fan motor 1 AV
1- 9 RMOTEA355WRE0 Fan motor (Interchangeable) 1 AU
1-10 QSOCLA021WRE0 Oven lamp socket 1 AH
1-11 RLMPTA081WRZZ Oven lamp 1 AK
1-11 RLMPTA068WRE0 Oven lamp (Interchangeable) 1 AG
1-12 RMOTDA186WRE0 Turntable motor 1 AW
1-12 RMOTDA211WRE0 Turntable motor (Interchangeable) 1 AS
1-13 RTHM-A120WRE0 Thermal cut-out 145 deg. 1 AH
1-13 RTHM-A080WRE0 Thermal cut-out 145 deg. (Interchangeable) 1 AP
1-14 RTRN-A576WRE0 Power transformer 1 BM
CABINET PARTS
2- 1 GCABUA690WRP0 Outer case cabinet 1 AZ
2- 2 GDAI-A316WRW0 Bottom plate 1 AX
2- 3 GLEGPA074WRE0 Foot 2 AC
2- 4 GLEGPA077WRF0 Leg 1 AH
CONTROL PANEL PARTS
3- 1 DPWBFC021WRKZ Power unit 1 BA
3- 1A QCNCMA446DRE0 2-pin connector (CN-A) 1 AC
3- 1B FW-VZA250DRE0 9pin wire harness (CN-C) 1 AW
3- 1C FW-VZA195DRE0 Switch harness A (SH-A) 1 AD
3- 1D FW-VZA256DREZ Switch harness B (SH-B) 1 AF
C1 VCEAB31EW108M Capacitor 1000 uF 25V 1 AE
D1 RSRCDA013DRE0 Diode bridge (S1NB10) 1 AG
RY1 RRLY-A094DRE0 Relay (OMIF-S-112LM) 1 AN
RY2 RRLY-A114DRE0 Relay (DU12D1-1P(M)-R) 1 AN
SP1 RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
T1 RTRNPA110DRE0 Transformer 1 AP
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
3- 2 DPWBFC163WRKZ CPU unit 1 BN
3- 3 FPNLCB558WRKZ Control panel frame with key unit 1 BC
3- 3-1 FUNTKB049WREZ Key unit 1 AV
3- 4 PSHEPA588WRE0 LED sheet 1 AE
3- 5 LHLD-A205WRF0 LCD holder 1 AF
3- 6 XEPSD30P08XS0 Screw; 3mm x 8mm 4 AA
OVEN PARTS
4- 1 PDUC-A724WRF0 Air separater 1 AU
4- 2 PPACGA084WRF0 TTM packing 1 AF
4- 3 PHOK-A116WRFZ Latch hook 1 AH
4- 4 LBNDKA099WRW0 Capacitor holder 1 AD
4- 5 NFANJA029WRE0 Fan blade 1 AL
4- 6 PDUC-A728WRW0 Fan duct 1 AT
4- 7 ************* Oven cavity (Not a replaceable part) 1--
4- 8 LANGFA194WRW0 Chassis support 1 AU
4- 9 PCUSGA321WRP0 Cushion 1 AH
4-10 LANG-A079WRWZ Air guide 1 AF
4-11 LANG-A078WRWZ Barrier 1 AF
4-12 NCPL-A053WRFZ Coupling 1 AE
4-13 PCUSUA511WRP0 Cushion 1 AC
4-14 PCOVPA349WRE0 Waveguide cover 1 AE
4-15 PCUSGA339WRP0 Cushion 1 AG
