Sharp R-350D Service Manual

R-350D
32
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 3. PART NO.
2. REF. NO. 4. DESCRIPTION
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
∆
4-16 PCUSUA527WRP0 Cushion 1 AE
4-17 PCUSUA512WRP0 Cushion 1 AB
4-18 PCUSUA474WRP0 Cushion 2 AC
4-19 LANG-A079WRWZ Air guide 1 AF
4-20 PCUSGA533WRP0 Cushion 1 AD
4-21 PCUSUA157WRP0 Cushion 1 AC
4-22 PCUSUA212WRP0 Cushion 1 AB
4-23 PCUSUA461WRP0 Cushion 1 AB
DOOR PARTS
5- 1 FDORFA332WRT0 Door panel 1 BB
5- 2 PSHEPA382WRE0 Sealer film 1 AH
5- 3 GWAKPA715WRRZ Door frame 1 AX
5- 4 HPNL-A745WRRZ Door screen 1 AR
5- 5 LSTPPA193WRFZ Latch head 1 AE
5- 6 MSPRTA187WRE0 Latch spring 1 AC
5- 7 XCPSD40P08000 Screw : 4mm x 8mm 6 AA
5- 8 PCUSUA461WRP0 Cushion 1 AB
5- 9 PCUSUA553WRPZ Cushion 2 AC
5-10 PCUSUA554WRPZ Cushion 2 AB
5-11 GCOVHA417WRFZ Choke cover 1 AG
AHMISCELLANEOUS
6- 1 FROLPA079WRK0 Turntable support 1 AQ
6- 2 NTNT-A079WRE0 Turntable tray 1 AR
6- 3 FW-VZB792WREZ Main wire harness 1 AT
6- 4 FW-VZB752WRE0 Switch harness 1 AG
6- 5 PZET-A012WRE0 Terminal insulator 1 AB
6- 6 TCAUHA214WRR0 Caution label 1 AC
6- 7 TSPCNC920WRRZ Rating label 1 AB
6- 8 TINSEA855WRRZ Instruction book 1 AK
6- 9 LHLDWA011WRE0 Purse lock M 1 AB
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 Screw : 4mm x 8mm 12 AA
7- 2 XHPSD30P06000 Screw : 3mm x 6mm 1 AA
7- 3 XHTSD40P08RV0 Screw : 4mm x 8mm 7 AA
7- 4 XOTSE40P08000 Screw : 4mm x 8mm 1 AA
7- 5 XOTSD40P12RV0 Screw : 4mm x 12mm 5 AA
7- 6 XOTSD40P12000 Screw : 4mm x 12mm 19 AA
7- 7 LX-CZ0052WRE0 Special screw 2 AA
