Sharp R-390AW - Oven and Cabinet Parts Diagram

10
R-390Aw
R-390AK
REF. NO. PART NO. DESCRIPTION Q'TY CODE
3- 7 JBTN-B081WRF0 Book mark button 1 AF
3- 8 JBTN-B080WRF0 Page button 1 AF
3- 9 JBTN-B079WRF0 Select button 1 AF
3- 10 JBTN-B078WRF0 Start button 1 AF
3- 11 MSPRCA050WRE0 Open button spring 1 AB
3- 12 MSPRCA104WRE0 Select button spring 1 AD
3- 13 XEPSD30P08XS0 Screw: 3mm x 8mm 9 AA
OVEN PARTS
4- 1 MLEVFA082WRE0 Actuator 1 AD
4- 2 PHOK-A104WRF0 Switch holder 1 AF
4- 3 PHOK-A095WRF0 Latch hook 1 AN
4- 4 LBNDKA099WRW0 Capacitor holder 1 AD
4- 5 NFANJA029WRE0 Fan blade 1 AL
4- 6 PDUC-A652WRP0 Fan duct 1 AU
4- 7 ************* Oven cavity (Not a replaceable part) 1BC
4- 8 LANGFA175WRP0 Chassis support 1 AX
4- 9 LANGQA452WRP0 Partition angle 1 AK
4-10 LANGQA454WRP0 MG thermo angle 1 AH
4-11 MLEVPA194WRF0 Switch lever 1 AG
4-12 NCPL-A045WRF0 Coupling 1 AH
4-13 PCUSGA385WRP0 Cushion 1 AK
4-14 PCOVPA275WRE0 Waveguide cover 1 AR
4-15 PCUSGA339WRP0 Cushion 1 AG
4-16 PCUSUA212WRP0 Cushion 1 AB
4-18 PCUSUA376WRP0 Cushion 1 AG
4-19 PCUSUA192WRP0 Cushion 1 AD
4-20 PCUSUA329WRP0 Cushion 1 AC
4-21 PCUSGA399WRE0 Cushion 1 AG
4-22 PPACGA084WRF0 TTM packing 1 AF
4-23 LANGTA338WRP0 Sensor mounting angle 1 AN
DOOR PARTS
5- 1 FDORFA318WRT0 Door panel 1 BE
5- 2 PSHEPA382WRE0 Sealer film 1 AH
5- 3 GWAKPA531WRR0 Door frame 1 AT
5- 4 HPNL-A663WRR0 Door screen 1 AL
5- 5 GCOVHA385WRF0 Choke cover 1 AG
5- 6 LSTPPA139WRF0 Latch head 1 AF
5- 7 MSPRTA084WRE0 Latch spring 1 AB
5- 8 PCUSUA481WRP0 Cushion 1 AB
5- 9 PCUSUA452WRP0 Cushion 1 AB
5-10 XCPSD40P08000 Screw : 4mm x 8mm 1 AA
5-11 XCPSD40P08WN2 Screw : 4mm x 8mm 1 AC
MISCELLANEOUS
6- 1 FROLPA079WRK0 Turntable support 1 AQ
6- 2 NTNT-A079WRE0 Turntable tray 1 AR
6- 3 FW-VZB572WRE0 Main wire harness 1 BC
6- 4 QW-QZA150WRE0 High voltage wire B 1 AF
6- 5 PZET-A012WRE0 Terminal insulator 1 AB
6- 6 TCAUAA166WRR0 DHHS caution label 1 AC
6- 7 TCAUAA200WRR0 Monitor caution label 1 AB
6- 8 TCADCA655WRR0 Instruction book 1 AY
6- 9 TLABMA550WRR0 Copyright label 1 AD
SCREWS,NUTS AND WASHERS
7- 1 XFPSD40P08K00 Screw : 4mm x 8mm 7 AA
7- 2 XFPSD30P06000 Screw : 3mm x 6mm 3 AA
7- 3 XHTSD40P08RV0 Screw : 4mm x 8mm 3 AA
7- 4 XHTSD40P12RV0 Screw : 4mm x 12mm 1 AA
7- 5 XOTSD40P12RV0 Screw : 4mm x 12mm 8 AA
7- 6 XOTSD40P12000 Screw : 4mm x 12mm 14 AA
7- 7 XOTSE40P08000 Screw : 4mm x 8mm 1 AA
7- 8 XOTSD40P14000 Screw : 4mm x 14mm 1 AA
