Sharp R-42CV(ST) User Manual

6
OVEN DIAGRAM
OVEN:
1. LED Display
2. Control panel
3. Oven lamp
4. Door open button
5. Waveguide cover
(
Do not remove
)
6. Coupling
7. See through door
8. Door seals and sealing surfaces
9. Door safety latches
10. Top grill heating element
11. Ventilation openings
12. Door hinges
13. Oven cavity
14. Power supply cord
15. Outer cabinet
ACCESSORIES:
16. Turntable
17. Roller stay
18. Low rack
19. High rack
• Place the roller stay in the centre of the oven
floor, then place the turntable on to the roller
stay, ensuring it is located firmly into the
coupling.
• To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim
when removing them from the oven.
• The racks are for Grill, Combi., Convection and
recommended automatic operations.
Never touch the grill when it is hot.
16
17
11
14
15
2
1
10
3
4
56
7
89
12
13
19
18
NOTES:
• The waveguide cover is fragile. Care should be taken when cleaning inside the oven to ensure that it is not
damaged.
• After cooking fatty foods without a cover, always clean the cavity and especially the grill heating elements
thoroughly, these must be dry and free from grease. Built-up grease may overheat and begin to smoke or
catch fire.
• Always operate the oven with the turntable fitted correctly. This promotes thorough, even cooking. A badly
fitted turntable may rattle, may not rotate properly and could cause damage to the oven.
• The turntable rotates clockwise or anti-clockwise. The rotary direction may change each time you start the
oven. This does not affect cooking performance.
Warning:
The accessories will become very hot whenever the the grill or convection symbols are lit on the display.
Use thick oven mittens when inserting/removing the food or turntable from the oven to prevent burns.
