Sharp R-55TS - Page 40

38
R-55TS
REF. NO. PART NO. DESCRIPTION Q'TY CODE
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.
∆
∆
∆
∆
4-30 PSKR-A396WRPZ Reflector right 1 AK
4-31 PSLDHA173WRPZ Upper thermal cover 1 AK
4-32 PSLDHA175WRPZ Left thermal cover 1 AG
4-33 MSPRCA135WREZ Turntable spring 1 AD
4-34 PCOVPA369WREZ Waveguide cover 1 AD
4-35 MLEVPA247WRFZ Switch lever 1 AF
4-36 GCOVAA321WRPZ Exhaust cover 1 AH
4-37 GCOVAA322WRPZ Rear cover 1 AR
4-38 PSKR-A395WRPZ Rear reflector 1 AE
DOOR PARTS
5 DDORFB080WRKZ Door assembly 1 BM
5- 1 GCOVHA457WRFZ Choke cover 1 AT
5- 2 LSTPPA221WRFZ Latch head 1 AH
5- 3 LSTPPA222WRFZ Glass stopper 1 AF
5- 4 FDORFA370WRKZ Door panel 1 BD
5- 5 MSPRTA218WREZ Latch spring 1 AE
5- 6 PGLSPA591WREZ Front door glass 1 AY
5- 7 XEPSD40P10000 Screw : 4mm x 8mm 2 AC
MISCELLANEOUS
6- 1 FTNT-A048WRMZ Turntable support 1 AQ
6- 2 TINSEA983WRRZ Operation manual 1 AG
6- 3 TLABMA911WRRZ Menu label 1 AE
6- 4 NTNT-A070WRH0 Turntable 1 AR
6- 5 FW-VZB979WREZ Main wire harness 1 AX
6- 6 TCAUAA283WRRZ Monitor caution 1 AT
6- 7 TCAUAA284WRRZ DHHS caution label 1 AS
SCREWS,NUTS AND WASHERS
7- 1 XCPSD40P06000 Screw : 4mm x 6mm 1 AA
7- 2 XFPSD40P10000 Screw : 4mm x 10mm 3 AA
7- 3 XFPSD40P08000 Screw : 4mm x 8mm 1 AA
7- 4 XFTSD40P08000 Screw : 4mm x 8mm 4 AA
7- 5 XHPSD30P06000 Screw : 3mm x 6mm 5 AA
7- 6 XCPSD30P08X00 Screw : 3mm x 8mm 1 AA
7- 6 XCPSD30P08X00 Screw : 3mm x 8mm 2 AA
7- 7 LX-BZA134WREZ Special screw 8 AB
7- 8 LX-BZA133WREZ Special screw 3 AB
7- 9 LX-BZA135WREZ Special screw 1 AB
7-10 LX-EZA064WREZ Special screw 2 AA
7-11 LX-CZA081WREZ Special screw 4 AB
7-12 XFTSD40P10000 Screw : 4mm x 10mm 2 AA
7-13 XCPSD40P08000 Screw : 4mm x 8mm 3 AA
7-14 XBPWW30P05K00 Screw : 3mm x 5mm 4 AA
7-15 XBTSD40P06000 Screw : 4mm x 6mm 1 AA
7-16 XHTSD40P12RV0 Screw : 4mm x 12mm 5 AA
7-17 XNESD40-32000 Nut : 4mm x 3.2mm 1 AA
7-18 XNEUW30-24000 Nut : 3mm x 2,.4m 1 AB
7-19 XOTSD40P08000 Screw : 4mm x 8mm 8 AA
7-20 XOTSD40P10000 Screw : 4mm x 10mm 16 AA
7-21 XOTWW40P10000 Screw : 4mm x 10mm 1 AA
7-22 XTTSD40P06000 Screw : 4mm x 6mm 6 AA
7-23 XUTSD40P10000 Screw : 4mm x 10mm 1 AA
7-24 XHTSD40P08RV0 Screw : 4mm x 8mm 2 AA
7-25 XFTSD40P08000 Screw : 4mm x 8mm 1 AA
7-26 LX-CZA070WRE0 Special screw (Torx tamper proof screw) 2 AC
