Sharp R-55TS - Parts List

37
R-55TS
*
*
*
*
*
∆
*
*
∆
∆
∆
∆
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 QSW-MA085WRE0 Secondary interlock switch / Door sensing switch 2 AF
1- 2 FFS-BA036WRKZ
C/T fuse(150C 15A) and monitor switch(V-5220Q) assembly 1AM
1- 3 FH-HZA082WREZ Thermistor assembly 1 AK
1- 4 FACCDA082WRE0 Power supply cord 1 AV
1- 4 FACCDA086WREZ Power supply cord (Interchangeable) 1 AN
1- 5 RC-QZA313WRZZ High voltage capacitor 1 AP
1- 5 RC-QZA307WRZZ High voltage capacitor (Interchangeable) 1 AX
1- 5 RC-PZA041WRE0 High voltage capacitor (Interchangeable) 1 AS
1- 6 RH-DXA001WRZZ High voltage rectifier 1 AG
1- 6 RH-DXA002WRZZ High voltage rectifier (Interchangeable) for production use 1--
1- 7 RHET-A279WRZZ Lower heater 1 AM
1- 8 RMOTEA420WRZZ Fan motor 1 AU
1- 9 RMOTDA186WRE0 Turntable motor 1 AW
1-10 RLMPTA085WRZZ Oven lamp 1 AH
1-10 RLMPTA082WRZZ Oven lamp (Interchangeable) 1 AL
1-11 RV-MZA261WRE0 Magnetron 1 BF
1-12 RRLYDA012DRZZ Select relay 1 AN
1-13 RTRN-A707WRZZ Power transformer 1 BE
1-14 RTHM-A110WRE0 Oven thermostat 150
C 1AK
1-15 RTHM-A098WRE0 Thermal cut out 125 C 1AK
1-16 RHET-A278WRZZ Upper heater 1 AN
CABINET PARTS
2- 1 FDAI-A266WRKZ Bottom plate assembly 1 AU
2- 2 GLEGPA091WREZ Leg 4 AC
2- 3 GCABUA896WRPZ Outer case cabinet 1 AU
CONTROL PANEL PARTS
3- 1 XEBSD30P08000 Screw 3mm x 8mm 12 AA
3- 2 DPWBFC339WRKZ Control unit 1 BH
3- 3 FPNLCB754WRKZ Panel sub assembly 1 BB
3-3-1 JBTN-B246WRFZ Open button 1 AH
3-3-2 JBTN-B247WRFZ Select button 1 AQ
3-3-3 MSPRCA143WREZ Button spring 1 AE
3-3-4 FKNBKA217WRKZ Timer knob assembly 1 AQ
3-4 PCUSGA617WRPZ LCD cushion 3 AB
OVEN PARTS
4- 1 PHOK-A132WRFZ Latch hook 1 AH
4- 2 LBNDKA151WRPZ Capacitor band 1 AE
4- 3 PFPF-A220WREZ Lower thermal insulation 1 AE
4- 4 PSLDHA164WRWZ Bottom reflector 1 AG
4- 5 NFANJA049WREZ Fan blade 1 AG
4- 6 XXXXXXXXXXXXX Oven cavity assembly (Not replaceable part) 1 --
4- 7 LANGKA933WRPZ Sensor mounting angle 1 AL
4- 8 LANGKB054WRPZ Shaft stopper 1 AM
4- 9 FSFTTA043WREZ Turntable shaft assembly 1 AQ
4-10 LHLD-A220WRPZ Turntable motor mounting angle 1 AL
4-11 NGERHA136WRFZ Turntable gear A 1 AH
4-12 GGADUA002WREZ Heater guard 1 AD
4-13 PDUC-A846WRPZ Air duct 1 AH
4-14 LANGKB049WRPZ Reflector 1 AE
4-15 LANGKB047WRPZ Relay mounting angle 1 AE
4-16 LANGKB056WRPZ Insertion barrier A 1 AE
4-17 LANGKB063WRPZ Support angle 1 AF
4-18 LANGQA546WRPZ Thermistor angle 1 AD
4-19 LANGTA381WRPZ Chassis support 1 AE
4-20 LANGTA395WRPZ Cavity support angle 1 AF
4-21 LSTPPA212WRFZ Door stopper 1 AC
4-22 LANGKB053WRPZ Door insertion barrier 1 AE
4-23 LANGKB048WRPZ Fan duct 1 AP
4-24 MHNG-A479WRPZ Lower oven hinge 1 AE
4-25 MHNG-A480WRPZ Upper oven hinge 1 AF
4-26 LANGKA987WRPZ Heater fix angle left 1 AC
4-27 LANGKA986WRPZ Heater fix angle right 1 AC
4-28 PCUSGA569WRPZ Cushion 1 AB
4-29 PDUC-A802WRPZ Exhaust duct 1 AE
