18
SPECIFICATIONS
AC Line Voltage : Single phase 220-230V, 50Hz
AC Power Required :
Microwave 1.25 kW
Grill 0.95 kW (at 220V)
1.05 kW (at 230V)
Output Power :
Microwave 800W* (IEC test procedure)
Grill Heater 900W (at 220V)
1000W (at 230V)
Microwave Frequency : 2450 MHz **(Class B/Group 2)
Outside Dimensions : 450mm(W) x 320mm(H) x 362mm(D)
Cavity Dimensions : 285mm(W) x 202mm(H) x 298mm(D)***
Oven Capacity : 17 liters (0.6 cu.ft)***
Cooking Uniformity : Turntable (272mm tray) system
Weight : Approx. 13kg
SHARP CORPORATION OSAKA, JAPAN
TINSRA613WRRZ-Z72
SERVICE CALL CHECK
Check the following before calling service:
1. Does the display light? Yes
No
2. When the door is opened, does the oven lamp come on? Yes No
3. Place one cup of water (approx. 250 ml) in a glass measuring cup in the oven and close the door
securely. Oven lamp should go off if door is closed properly.
Programme the oven for one minute on HIGH. At this moment:
A. Does the oven lamp light? Yes
No
B. Does the cooling fan work? Yes No
(Put your hand over the rear ventilation openings.)
C. Does the turntable rotate? Yes No
(The turntable can rotate clockwise or counterclockwise. This is quite normal.)
D. Do the microwave symbol and COOK indicator light? Yes
No
E. After one minute, did an audible signal sound? Yes No
F. Is the water inside the oven hot? Yes No
4. Remove water from the oven and programme the oven for 3 minutes on GRILL mode.
A. Does the GRILL and COOK indicator light? Yes
No
B. After 3 minutes, does the heater become red? Yes No
If "NO" is the answer to any of the above questions, please check your wall socket and the fuse in your
meter box.
If both the wall socket and the fuse are functioning properly, CONTACT YOUR NEAREST SERVICE
CENTER APPROVED BY SHARP.
NOTE: The following things are not trouble;
1. After any cooking for 3 minutes or more,the cooling fan will remain on until the oven cavity
has cooled. Therefore you may feel air blowing from the ventilation openings.
2. Each cooking mode has a maximum cooking time. If you operate the oven longer than the
maximum time, the power will automatically be reduced. The table below shows the
maximum time for each cooking mode.
* This measurement is based on the International Electrotechnical Commission's standardised
method for measuring output power.
** This is the classification of ISM (Industrial, Scientific and Medical) equipment described in the
International Standard CISPR11.
*** Internal capacity is calculated by measuring maximum width, depth and height.
Actual capacity for holding food is less.
Maximum cooking time
20 min.
10 min.
Cooking mode
Microwave 100% cooking
Grill cooking/Grill Mix-Low cooking
