16
R-7A55(W)/(B)
R-7E45(W)/(B)
COMPONENT TEST
TEST PROCEDURES (CONT'D)
PROCEDURE
LETTER
J FUSE F1 15A
CARRY OUT 3D CHECKS
If the fuse
F1 15A is blown, there is a shorts or grounds in electrical parts or wire harness. Check them
and replace the defective parts or repair the wire harness.
CARRY OUT
4R CHECKS
CAUTION: Only replace fuse with the correct value replacement.
K BLOWN FUSE F2 F6.3A
CARRY OUT 3D CHECKS
1. If the fuse
F2 F6.3A is blown when the door is opened, check the 1st latch switch, monitor switch and
monitor resistor.
2. If the fuse
F2 F6.3A is blown by incorrect door switching replace the defective switch(es) and the fuse
F2 F6.3A.
3. If the fuse
F2 F6.3A is blown, there could be a shorts or grounds in electrical parts or wire harness.
Check them and replace the defective parts or repair the wire harness.
CARRY OUT
4R CHECKS
CAUTION: Only replace fuse
F2 F6.3A with the correct value replacement.
L BLOWN FUSE F3 F10A
CARRY OUT
3D CHECKS
1. If the fuse
F3 F10A is blown, there could be shorts or grounds in electrical parts or wire harness.
Check them and replace the defective parts or repair the wire harness.
2. If the fuse
F3 F10A is blown, there could be shorts in the asymmetric rectifier or there is a ground
in wire harness. A short in the asymmetric rectifier may be occurred due to short or ground in H.V.
rectifier, magnetron, high voltage transformer or H.V. wire. Check them and replace the defective
parts or repair the wire harness.
CARRY OUT
4R CHECKS
CAUTION: Only replace fuse
F3 F10A with the correct value replacement.
M CONVECTION HEATING ELEMENT AND GRILL HEATING ELEMENT TEST
CARRY OUT
3D CHECKS
Before carrying out the following tests make sure the heating element is cool completely.
1. Resistance of heating element.
Disconnect the wire leads to the heating element to be tested. Using ohmmeter with low resistance
range. Check the resistance across the terminals of the heating element as described in the following
table.
Table: Resistance of heating element
Parts name Resistance
Convection heating element Approximately 39 Ω
Grill heating element Approximately 22 Ω x 2 = 44 Ω
2. Insulation resistance.
Disconnect the wire leads to the heating element to be tested. Check the insulation resistance
between the element terminal and cavity using a 500V - 100MΩ insulation tester. The insulation
resistance should be more than 10M&ohm in the cold start.
If the results of above test 1 and/or 2 are out of above specifications, the heating element is probably
faulty and should be replaced.
CARRY OUT
4R CHECKS
To Next Page
