Sharp R-7A55 User Manual

39
R-7A55(W)/(B)
R-7E45(W)/(B)
ELECTRIC PARTS
C RC-QZA129WRE0 U High voltage capacitor 1 AW
CH RHET-A117WRE0 U Convection heating element 1 AW
CM RMOTEA285WRE0 U Convection motor 1 AW
F1 QFS-CA016WRE0 J Fuse 15A 1 AD
F2 QFS-CA011WRE0 J Fuse F6.3A 1 AC
F3 QFS-CA020WRE0 U Fuse F10A 1 AB
FM RMOTEA278WRE0 U Fan motor 1 AT
GH FHET-A045WRK0 U Grill heating element assembly 1 BB
MG RV-MZA177WRE0 U Magnetron .1 BG
OL RLMPTA034WRE0 U Oven lamp 1 AK
R1 RR-WZA020WRE0 J Monitor resistor 4.3Ω 20W 1 AF
SW1 QSW-MA110WRE0 J 1st latch switch 1 AK
SW2 QSW-MA110WRE0 J 2nd latch switch 1 AK
SW3 QSW-MA110WRE0 J Stop switch 1 AK
SW4 QSW-MA112WRE0 J Monitor switch 1 AN
SW5 QSW-MA110WRE0 J Damper switch 1 AK
T RTRN-A382WRE0 U High voltage transformer 1 BN
TC1 RTHM-A084WRE0 U Thermal cut-out 170˚C (OVEN) 1 AL
TC2 RTHM-A078WRE0 U Thermal cut-out 125˚C (MG) 1 AL
TC3 RTHM-A004WRE0 J Thermal cut out 190˚C (CONV.) 1 AL
DM RMOTDA183WRE0 U Damper motor 1 AV
TTM RMOTDA148WRE0 J Turntable motor 1 AP
1- 1 FH-HZA007WRE0 U Thermistor 1 AH
1- 2 RTRN-A401WRE0 J TC transformer 1 AW
1- 3 FACCVA003WRK0 U Power supply cord assembly 1 AP
1- 4 FH-DZA033WRE0 U High voltage rectifier assembly 1 AP
1- 5 FPWBFA276WRE0 U Noise filter 1 AW
1- 6 QFSHDA002WRE0 U Fuse holder 1 AE
1- 7 QSOCLA011WRE0 J Oven lamp socket 1 AH
CABINET PARTS
2- 1 GCABDA064WRP0 U Back plate 1 AP
2- 2 GCABDA065WRP0 U Sub back plate 1 AH
2- 3 GCABUA445WRP0 U Outer case cabinet (Brown) 1 AX
2- 3 GCABUA444WRP0 U Outer case cabinet (White) 1 AX
2- 4 MHNG-A325WRM0 U Lower oven hinge 1 AC
2- 5 GDAI-A219WRP2 U Base plate 1 AS
2- 6 GLEGPA028WRE0 U Foot 4 AA
CONTROL PANEL PARTS
3- 1 CPWBFA564WRK0 J Control unit 1 BT
3- 1A QCNCMA227DRE0 J 9-pin connector (A) 1 AC
3- 1B QCNCMA267DRE0 J 6-pin connector (B) 1 AC
3- 1C QCNCWA030DRE0 J 12-pin connector (G) 1 AE
3- 1D QCNCMA346DRE0 J 6-pin connector (H) 1 AK
3- 1E RV-KXA058DRE0 J Fluorescent display tube 1 AY
C1 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AB
C2 RC-EZA238DRE0 J Capacitor 1000 uF 35V 1 AD
C3 RC-EZA229DRE0 J Capacitor 47 uF 16V 1 AB
C4-5 VCKYD11CY103N J Capacitor 0.01 uF 16V 2 AH
C10 VCTYF31HF103Z J Capacitor 0.01 uF 16V 1 AB
C20 RC-EZA302DRE0 J Capacitor 0.1 uF 50V 1 AA
C21 RC-EZA305DRE0 J Capacitor 4.7 uF 35V 1 AA
C40 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AH
C50 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AH
C60 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AH
C90 RC-EZA320DRE0 J Capacitor 47 uF 35V 1 AR
CF1 RCRS-A012DRE0 J Ceramic resonator (CST4.00MGW) 1 AD
CR70 RMPTEA011DRE0 J CR array 1 AL
D1 RSRCDA013DRE0 J Diode bridge (S1NB10) 1 AG
D20-28 VHD1SS270A/-1 J Diode (1SS270ATA) 9 AA
D40 VHD1SS270A/-1 J Diode (1SS270ATA) 1 AA
D72-77 VHD1SS270A/-1 J Diode (1SS270ATA) 6 AA
IC1 RH-IZA516DRE0 J LSI 1 AU
Q1 VS2SA933S//-3 J Transistor (2SA933S) 1 AB
Q2 VS2SB910MR/-4 J Transistor (2SB910M) 1 AE
Q3 VSDTA114ES/-3 J Transistor (DTA114ES) 1 AB
Q21 VSDTD143EA/-4 J Transistor (DTD143EA) 1 AC
Q22-23 VSDTB143ES/-3 J Transistor (DTB143ES) 2 AC
Q24 VSDTA143ES/-3 J Transistor (DTA143ES) 1 AB
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure. / The parts marked "*" are used in
voltage more than 250V. / "§" Mark: Spare parts delivery section
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
∆
*
*
*
*
∆
