40
R-7A55(W)/(B)
R-7E45(W)/(B)
Note: The parts marked "∆" may cause undue microwave exposure. / The parts marked "*" are used in
voltage more than 250V. / "§" Mark: Spare parts delivery section
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
Q25 VSDTB143ES/-3 J Transistor (DTB143ES) 1 AC
Q26-27 VSDTC143ES/-3 J Transistor (DTC143ES) 2 AB
Q60 VSDTC114ES/-3 J Transistor (DTC114ES) 2 AB
R1 VRD-B12HF432J J Resistor 4.3k ohm 1/2W 1 AH
R2 VRD-B12HF102J J Resistor 1k ohm 1/2W 1 AA
R3 VRD-B12HF122J J Resistor 1.2k ohm 1/2W 1 AA
R4 VRD-B12EF102J J Resistor 1k ohm 1/4W 1 AA
R5 VRD-B12EF153J J Resistor 15k ohm 1/4W 1 AA
R10 VRD-B12EF473J J Resistor 47k ohm 1/4W 1 AA
R11 VRD-B12EF563J J Resistor 56k ohm 1/4W 1 AA
R20 VRD-B12EF471J J Resistor 470 ohm 1/4W 1 AA
R30 VRD-B12EF332J J Resistor 3.3k ohm 1/4W 1 AA
R31 VRD-B12EF102J J Resistor 1k ohm 1/4W 1 AA
R40 VRD-B12EF101J J Resistor 100 ohm 1/4W 1 AA
R41 VRD-B12EF512J J Resistor 5.1k ohm 1/4W 1 AA
R50 VRD-B12EF101J J Resistor 100 ohm 1/4W 1 AA
R51 VRD-B12EF512J J Resistor 5.1k ohm 1/4W 1 AA
R60 VRN-B12EK913F J Resistor 91k ohm 1/4W 1 AA
R61 VRN-B12EK101F J Resistor 100 ohm 1/4W 1 AA
R62 VRN-B12EK272F J Resistor 2.7k ohm 1/4W 1 AA
R80 VRD-B12EF105J J Resistor 1M ohm 1/4W 1 AA
R93 VRD-B12EF152J J Resistor 1.5k ohm 1/4W 1 AA
R94 VRS-B13AA121J J Resistor 120 ohm 1W 1 AA
R96-97 VRS-B13AA101J J Resistor 100 ohm 1W 2 AA
RY1 RRLY-A093DRE0 J Relay (VRB18) 1 AL
RY2 RRLY-A092DRE0 J Relay (VRB18SP) 1 AL
RY3 RRLY-A093DRE0 J Relay (VRB18) 1 AL
RY4 RRLY-A080DRE0 J Relay (OJ-SH-124LM) 1 AG
RY5 RRLY-A093DRE0 J Relay (VRB18) 1 AL
RY6-7 RRLY-A080DRE0 J Relay (OJ-SH-124LM) 2 AG
SP30 RALM-A014DRE0 J Buzzer (PKM22EPT-THAI) 1 AG
VRS1 RH-VZA010DRE0 J Varistor (15G471K-T) 1 AE
ZD1 VHEHZ6A3///-1 J Zener diode (HZ6A3) 1 AA
ZD2 VHEHZ4C3///-1 J Zener diode (HZ4C-3) 1 AA
ZD3 VHEHZ202///-1 J Zener diode (HZ20-2) 1 AB
3- 2 DUNTKA579WRK0 J Key unit assembly [R-7A55(B)] 1 BB
3- 2 DUNTKA580WRK0 J Key unit assembly [R-7A55(W)] 1 BB
3- 2 DUNTKA577WRK0 J Key unit assembly [R-7E45(B)] 1 BB
3- 2 DUNTKA578WRK0 J Key unit assembly [R-7E45(W)] 1 BB
3- 3 GMADIA076WRF0 U Display window 1 AD
3- 4 HPNLCB147WRF0 U Control panel (B) 1 AM
3- 4 HPNLCB148WRF0 U Control panel (W) 1 AM
3- 5 JBTN-A871WRF0 U Open button (B) 1 AD
3- 5 JBTN-A872WRF0 U Open button (W) 1 AD
3- 6 MSPRCA045WRE0 U Open button spring 1 AA
3- 7 XEPSD30P10XS0 J Screw; 3mm x 10mm 5 AA
3- 8 XHPSD30P06000 J Screw; 3mm x 6mm 1 AA
OVEN PARTS
4- 1 DOVN-A372WRK0 U Oven cavity 1 BP
4- 2 LBNDKA089WRP0 U Capacitor holder 1 AE
4- 3 FDUC-A257WRK0 U Exhaust duct assembly 1 AT
4- 4 PSLDHA112WRP0 U Heater cover R 1 AL
4- 5 LANGQA308WRP0 U Convection motor mouting plate 1 AE
4- 6 NFANMA011WRP0 J Convection fan 1 AD
4- 7 FFANMA014WRY0 U Auxiliary fan assembly 1 AF
4- 8 FDUC-A261WRK0 U Convection duct assembly 1 AP
4- 9 PFPF-A172WRE0 U Rear heat intercept 1 AH
4-10 PPIPFA013WRE0 U Pipe 1 AE
4-11 PSKR-A268WRP0 U Conv. air angle A 1 AD
4-12 PSKR-A269WRP0 U Conv. air angle B 1 AD
4-13 PSLDHA113WRP1 U Rear heat cover 1 AH
4-14 PHOK-A078WRF2 U Latch hook 1 AH
4-15 FFANJA042WRK0 U Fan blade assembly 1 AE
4-16 PDUC-A503WRF2 U Fan duct 1 AK
4-17 GCOVHA312WRP0 U Bottom heat cover 1 AH
4-18 LANGFA155WRP4 U Chassis support 1 AF
4-19 LANGQA385WRP1 U Lamp mounting angle 1 AF
4-20 LANGQA350WRP0 U TTM support angle 1 AC
4-21 MHNG-A324WRM0 U Upper oven hinge 1 AD
4-22 MLEVFA074WRF2 U Open lever 1 AD
4-23 PPACGA108WRE0 U Packing 1 AC
4-24 PFTA-A023WRP0 U Damper 1 AE
4-25 NCPL-A043WRF0 U Coupling 1 AE
∆
∆
∆
