Sharp R-7A55 User Manual

41
R-7A55(W)/(B)
R-7E45(W)/(B)
4-26 NSFTTA107WRE0 U Damper shaft 1 AQ
4-27 PCOVPA263WRE0 U Waveguide cover 1 AD
4-28 PSPAGA001WRE0 U HVT cushion 1 AA
4-29 PFPF-A164WRE0 U Heater intercept R 1 AH
4-30 PCUSUA346WRP0 U Cushion 1 AA
4-31 PCUSUA379WRP0 U Damper cushion 1 AC
4-32 PCUSUA380WRP0 U Heater cushion 1 AA
4-33 PCUSUA381WRP0 U Cushion 2 AA
4-34 PDUC-A560WRF0 U Air intake duct B 1 AF
4-35 PDUC-A540WRF0 U Air intake duct 1 AG
4-36 PDUC-A543WRP0 U Air duct 1 AH
4-37 PFILWA042WRP0 U Lamp filter 1 AB
4-38 LANGQA386WRP0 U Thermistor angle 1 AE
4-39 MCAMPA076WRF0 U Damper cam 1 AB
4-40 LANGTA305WRP0 U Air separate angle 1 AF
4-41 PSKR-A279WRF0 U Air separator angle 1 AF
DOOR PARTS
5 CDORFA597WRK0 U Door assembly (Brown) 1 BM
5 CDORFA598WRK0 U Door assembly (White) 1 BM
5- 1 DDORFA659WRY0 J Door panel assembly 1 AY
5- 2 GCOVHA304WRF0 U Choke cover 1 AH
5- 3 GWAKPA296WRF0 U Door frame (Brown) 1 AT
5- 3 GWAKPA297WRF0 U Door frame (White) 1 AT
5- 4 LSTPPA124WRF0 U Latch head 1 AE
5- 5 MSPRTA141WRE0 U Latch spring 1 AA
5- 6 PGLSPA388WRE0 U Front door glass (Brown) 1 AX
5- 6 PGLSPA389WRE0 U Front door glass (White) 1 AX
5- 7 XEPSD30P06000 J Screw : 3mm x 6mm 6 AA
5- 8 LSTPPA127WRF0 U Glass stopper (Brown) 1 AC
5- 8 LSTPPA128WRF0 U Glass stopper (White) 1 AC
MISCELLANEOUS
6- 1 FAMI-A067WRK0 U High rack 1 AY
6- 2 FAMI-A075WRK0 U Low rack 1 AY
6- 3 FROLPA063WRK1 U Roller stay 1 BA
6- 4 NTNT-A059WRE0 U Turntable tray 1 BA
6- 5 FW-VZB278WRE0 U Stop switch harness 1 AP
6- 6 QW-QZA175WRE0 U High voltage wire A 1 AE
6- 7 QW-QZA176WRE0 U High voltage wire B 1 AE
6- 8 FW-VZB279WRE0 U Main harnes 1 BB
6- 9 TLABSA055WRR0 U Fuse label 1 AB
6-10 TINS-A412WRR0 U Operation manual for R-7A55(B)/(W) 1 AH
6-10 TINS-A411WRR0 U Operation manual for R-7E45(B)/(W) 1 AH
6-12 TSPCNB921WRR0 U Rating label 1 AH
6-13 TCADCA500WRR0 U Cook book 1 AQ
6-14 TLABMA372WRR0 U Menu label for R-7A55(W) only 1 AG
6-14 TLABMA370WRR0 U Menu label for R-7A55(B) only 1 AG
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 J Screw : 4mm x 8mm 1 AA
7- 2 XFPSD30P08000 U Screw : 3mm x 8mm 1 AA
7- 3 XWWSD50-06000 J Washer : 4mm x 0.6mm 1 AA
7- 4 XOTSF40P12000 J Screw : 4mm x 12mm (B) 4 AA
7- 4 XOTSC40P12000 J Screw : 4mm x 12mm (W) 4 AA
7- 5 XOTSD40P10000 J Screw : 4mm x 10mm 2 AA
7- 6 XHTSD40P08RV0 J Screw : 4mm x 8mm 3 AA
7- 7 XBTUW40P06000 J Screw : 4mm x 6mm 3 AA
7- 8 XCBWW30P06000 J Screw : 3mm x 6mm 6 AA
7- 9 XNEUW40-32000 J Nut : 4mm x 3.2mm 1 AA
7-10 XOTWW40P06000 J Screw : 4mm x 6mm 2 AA
7-11 XPSSP20-20000 J Pin 1 AA
7-12 XWHUW40-08000 J Washer : 4mm x 0.8mm 1 AA
7-13 XWSUW40-10000 J Washer : 4mm x 1.0mm 1 AA
7-14 XBPSD40P25000 J Screw : 4mm x 25mm 2 AA
7-15 XNESD40-32000 J Nut : 4mm x 3.2mm 2 AA
7-16 LX-EZA045WRE0 U Special screw 10 AA
7-17 XCPSD30P06000 J Screw : 3mm x 6mm 5 AA
7-18 XFPSD40P08000 J Screw : 4mm x 8mm 6 AA
7-19 XFPSD50P10KS0 J Screw : 5mm x 10mm 2 AC
7-20 XOTSD40P12RV0 J Screw : 4mm x 12mm 25 AA
7-21 XCTWW40P06000 J Screw : 4mm x 6mm 6 AA
7-22 XBPSD40P05000 J Screw : 4mm x 5mm 2 AA
7-23 XWHSD50-08000 J Washer : 5mm x 0.8mm 1 AA
Note: The parts marked "∆" may cause undue microwave exposure. / The parts marked "*" are used in
voltage more than 250V. / "§" Mark: Spare parts delivery section
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
∆
∆
∆
∆
*
*
