RCD1200M
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[2] DOOR AND CONTROL PANEL PARTS
CONTROL PANEL PARTS
3-1 PSHEPB332WREZ AN CPU protect sheet
3-2 DPWB-A573DRKZ BQ Control unit
3-3-1 FUNTKB179WREZ AU Key unit
3-3-2 GCOVAA389WRPZ AR C/P case
3-3-3 GMADIA189WRFZ AL Display window
3-3-4 GWAKPB142WRFZ AK Panel grille
3-3-5 HDECQA372WRMZ AL Panel cap R
3-3-6 HDECQA373WRMZ AL Panel cap L
3-3-7 LANGQA676WRWZ AP Panel fixing plate
3-3-8 PCUSGA753WRPZ AF CP cushion A
3-4 PCUSGA754WRPZ AC CP cushion B
3-5 XCPS730P08XS0 AC Screw : 3mm x 8mm
DOOR PARTS
* 5-1 FANGKA225WRYZ AN Latch angle assembly
* 5-2 FDORFA436WRYZ BB Door panel sub assembly
5-3 FCOV-A018WRKZ BE Door case assembly
* 5-3-1 GCOVAA392WRYZ BA Door case
* 5-3-2 GWAK-A012WRFZ AX Door frame
5-5 LSTPPA261WRFZ AG Glass stopper
5-6 PGLSPA727WREZ AS Front door glass
5-7 XEPS740P08000 AB Screw : 4mm x 8mm
* 5-8 GCOVHA525WRFZ AS Choke cover
5-9 JHNDMA058WRMZ BD Door handle
5-10 JHNDMA062WRPZ AK Handle lever
* 5-11 LSTPPA260WRFZ AG Latch head
5-12 MLEVFA091WRWZ AG Latch lever
5-13 MSPRTA190WRE0 AD Latch spring
5-14 PCOVPA476WRFZ AG Board cover
5-15 PCOVPA477WRFZ AM Handle cover
5-16 PCUSGA720WRPZ AG Latch ag cushion
5-17 PCUSGA736WRPZ AE Door cushion L
5-18 PCUSGA737WRPZ AF Door cushion S
5-19 PCUSGA738WRPZ AC Harness cushion
5-20 PPIPPA017WRFZ AF Pipe
5-21 PSHEPB325WREZ AK Key protect cover
5-24 HBDGCA129WRRZ AH Door badge
5-25 MSPRCA174WREZ AF Earth spring
5-26 DPWB-A569DRKZ BA Switch unit
5-27 FUNTKB180WREZ AS Key unit
5-28 FW-VZC153WREZ AS Harnes (Door key harness)
5-29 LANGTA440WRPZ AN Key fixing plate
5-30 LRTNPA001DRZZ AF connector
5-31 LRTNPA002DRZZ AF connector
5-32 XBPS740P25K00 AC Screw : 4mm x 25mm
5-33 XCPS730P08XS0 AC Screw : 3mm x 8mm
5-34 XEPS740P10000 AA Screw : 4mm x 10mm
5-35 LX-RZ180AKRE0 AA Special ring
MISCELLANEOUS
6-1 TCADRA030WRRZ AF Touch guide
6-2 TINSEB154WRRZ AP Instruction book
6-3 LHLDWA013WRE0 AC Purce lock
6-4 FW-VZC169WREZ BK Main wire harness
6-5 FW-VZC160WREZ AZ Harnes (CPU harnes)
6-7 FW-VZC155WREZ AG Harnes (Oven harness)
6-8 FW-VZC168WREZ AS Harnes (DC harness 12)
6-9 FW-VZC157WREZ AR Harness (Sensor harness)
6-12 LHLDWA011WRE0 AB Purce lock M
