9-5
9.5 Electrical main parts list (for TPR-1230H CE Standard)
Part No. Symbol Name Specification Q’ty Remark
E1602001 Key Switch XF163B 1
E0703002 M1 Magnetic Contact CN18 24V 1
E0703002 M2 Magnetic Contact CN18 24V 1
E0703001 M3 Magnetic Contact CN11 3a1b 24V 1
E0703001 M4 Magnetic Contact CN11 3a1b 24V 1
E0703001 M5 Magnetic Contact CN11 3a1b 24V 1
E0703001 M6 Magnetic Contact CN11 3a1b 24V 1
E0703001 M0 Magnetic Contact CN11 3a1b 24V 1
E3101027 FU1 Fuse 10*38*20A 1
E3101027 FU2 Fuse 10*38*20A 1
E3101027 FU3 Fuse 10*38*20A 1
E3101025 FU4 Fuse 10*38*6A 1
E0211001 CR1 Control Relay MK-2P 24V 1
E0211001 CR2 Control Relay MK-2P 24V 1
E0208001 T1 Timer Relay ASTP-N 24V 6S 1
E0208001 T2 Timer Relay ASTP-N 24V 6S 1
M0302019 SOL1 DSG-3C2-02-24V 1
M0302019 SOL2 DSG-3C2-02-24V 1
M0302019 SOL3 DSG-3C2-02-24V
1
M0302019 SOL4 DSG-3C2-02-24V
E0207017 OL1 Overload relay RHN 10/5.5~8.5 1
E0207014 OL2 Overload relay RHN 10/1.4~2.1 1
E0207014 OL3 Overload relay RHN 10/1.4~2.1 1
E0901021 SS1 Limit Switch V-15-1E5 4
E1303002 SS2 Selector Switch
YK∅30 1A1B (B)
1
E1604001 SS3 Selector Switch SN1021 1
E1603001 SS4 Pole change Switch A441 CA10 1
B100012 SS5 Push Button ZB4-BA2
ZB4-BZ101
ZBE-102
1
B100012 SS6 Push Button ZB4-BA2
ZB4-BZ101
ZBE-102
1
E1203001 PB1 Emg. Push Button
YK∅30 1A1B
1
E1202012 PB2 Push Button
YK∅22 2A (B)
1
E1202012 PB3 Push Button
YK∅22 2A (B)
1
E0901006 LS1 Limit Switch MJ2-1308R 1
To Next Page
