NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PART CODE
PRICE
RANK
DESCRIPTION
SD-AT1000H
– 6 –
RA155~158 VRS-CY1JB753D J AA 75 kohms,1/16W
RA159 VRS-CY1JB102J J AA 1 kohm,1/16W
RA161 VRS-CY1JB101J J AA 100 ohm,1/16W
RA170,171 VRS-CY1JB472J J AA 4.7 kohms,1/16W
RA172~175 VRS-CY1JB153D J AA 15 kohms,1/16W
RA204~207 VRS-CY1JB124D J AA 120 kohms,1/16W
RA208,209 VRS-CY1JB203D J AB 20 kohms,1/16W
RA222,223 VRS-CY1JB823J J AA 82 kohms,1/16W
RA224,225 VRS-CY1JB273J J AA 27 kohms,1/16W
RA226,227 VRS-CY1JB823J J AA 82 kohms,1/16W
RA228,229 VRS-CY1JB683J J AA 68 kohms,1/16W
RA230,231 VRS-CY1JB153D J AA 15 kohms,1/16W
RA232,233 VRS-CY1JB332D J AA 3.3 kohms,1/16W
RA234,235 VRS-CY1JB681D J AA 680 ohms,1/16W
RA236,237 VRS-CY1JB102D J AA 1 kohm,1/16W
RA238,239 VRS-CY1JB153D J AA 15 kohms,1/16W
RA240,241 VRS-CY1JB332D J AA 3.3 kohms,1/16W
RA242,243 VRS-CY1JB681D J AA 680 ohms,1/16W
RA244,245 VRS-CY1JB102D J AA 1 kohm,1/16W
RA246~249 VRS-CY1JB562J J AA 5.6 kohms,1/16W
RA250,251 VRN-CM05N470J J AE 47 ohms,5W,Metal Film
RA252,253 VRS-CY1JB472J J AA 4.7 kohms,1/16W
RA255~258 VRS-CY1JB753D J AA 75 kohms,1/16W
RA259 VRS-CY1JB102J J AA 1 kohm,1/16W
RA261 VRS-CY1JB101J J AA 100 ohm,1/16W
RA270,271 VRS-CY1JB472J J AA 4.7 kohms,1/16W
RA272~275 VRS-CY1JB153D J AA 15 kohms,1/16W
RA304~307 VRS-CY1JB124D J AA 120 kohms,1/16W
RA308,309 VRS-CY1JB203D J AB 20 kohms,1/16W
RA322,323 VRS-CY1JB823J J AA 82 kohms,1/16W
RA324,325 VRS-CY1JB273J J AA 27 kohms,1/16W
RA326,327 VRS-CY1JB823J J AA 82 kohms,1/16W
RA328,329 VRS-CY1JB683J J AA 68 kohms,1/16W
RA330,331 VRS-CY1JB153D J AA 15 kohms,1/16W
RA332,333 VRS-CY1JB332D J AA 3.3 kohms,1/16W
RA334,335 VRS-CY1JB681D J AA 680 ohms,1/16W
RA336,337 VRS-CY1JB102D J AA 1 kohm,1/16W
RA338,339 VRS-CY1JB153D J AA 15 kohms,1/16W
RA340,341 VRS-CY1JB332D J AA 3.3 kohms,1/16W
RA342,343 VRS-CY1JB681D J AA 680 ohms,1/16W
RA344,345 VRS-CY1JB102D J AA 1 kohm,1/16W
RA346~349 VRS-CY1JB562J J AA 5.6 kohms,1/16W
RA350,351 VRN-CM05N470J J AE 47 ohms,5W,Metal Film
RA352,353 VRS-CY1JB472J J AA 4.7 kohms,1/16W
RA355~358 VRS-CY1JB753D J AA 75 kohms,1/16W
RA359 VRS-CY1JB102J J AA 1 kohm,1/16W
RA361 VRS-CY1JB101J J AA 100 ohm,1/16W
RA370,371 VRS-CY1JB472J J AA 4.7 kohms,1/16W
RA372~375 VRS-CY1JB153D J AA 15 kohms,1/16W
RA400~402 VRS-CY1JB102J J AA 1 kohm,1/16W
RA403~405 VRS-CY1JB272J J AA 2.7 kohms,1/16W
RA406~408 VRS-CY1JB102J J AA 1 kohm,1/16W
RA409~414 VRS-CY1JB391J J AA 390 ohms,1/16W
RA415~420 VRN-VV3DAR10J J AB 0.1 ohm,2W,Metal Film
RA421,422 VRS-CY1JB334J J AA 330 kohms,1/16W
RA424 VRS-CY1JB223J J AA 22 kohms,1/16W
RA425 VRS-CY1JB473J J AA 47 kohms,1/16W
RA426 VRS-CY1JB683J J AA 68 kohms,1/16W
RA427 VRS-CY1JB223J J AA 22 kohms,1/16W
RA428 VRS-CY1JB823J J AA 82 kohms,1/16W
RA430 VRS-CY1JB104J J AA 100 kohm,1/16W
RA475 VRS-CY1JB103J J AA 10 kohm,1/16W
RA476 VRS-CY1JB472J J AA 4.7 kohms,1/16W
RA477 VRS-CY1JB473J J AA 47 kohms,1/16W
RA478 VRS-CY1JB102J J AA 1 kohm,1/16W
RA479 VRS-CY1JB473J J AA 47 kohms,1/16W
RA480 VRS-CY1JB103J J AA 10 kohm,1/16W
RA481 VRS-CY1JB473J J AA 47 kohms,1/16W
RM701,702 VRS-CY1JB103J J AA 10 kohm,1/16W
RM703 VRS-CY1JB180J J AA 18 ohms,1/16W
RM704 VRS-CY1JB220J J AA 22 ohms,1/16W
RM705 VRS-CY1JB224J J AA 220 kohms,1/16W
RM706,707 VRS-CY1JB151J J AA 150 ohms,1/16W
RM708 VRS-CY1JB681J J AA 680 ohms,1/16W
RM709~711 VRS-CY1JB331J J AA 330 ohms,1/16W
RM712 VRS-CY1JB182J J AA 1.8 kohms,1/16W
RM713 VRS-CY1JB331J J AA 330 ohms,1/16W
RM714 VRS-CY1JB182J J AA 1.8 kohms,1/16W
RM715 VRS-CY1JB820J J AA 82 ohms,1/16W
RM717 VRS-CY1JB473J J AA 47 kohms,1/16W
RM718,719 VRS-CY1JB103J J AA 10 kohm,1/16W
RM720 VRS-CY1JB683J J AA 68 kohms,1/16W
RM721 VRS-CY1JB103J J AA 10 kohm,1/16W
RM723 VRS-CY1JB472J J AA 4.7 kohms,1/16W
RM730~732 VRS-CY1JB820J J AA 82 ohms,1/16W
RS01 VRD-ST2CD472J J AA 4.7 kohms,1/6W
RS03 VRD-ST2CD472J J AA 4.7 kohms,1/6W
RS04 VRD-ST2CD105J J AA 1 Mohm,1/6W
RS05~07 VRD-ST2CD472J J AA 4.7 kohms,1/6W
RT21 VRS-CY1JB103J J AA 10 kohm,1/16W
RT24 VRS-CY1JB563J J AA 56 kohms,1/16W
RT25 VRS-CY1JB103J J AA 10 kohm,1/16W
RT26 VRS-CY1JB563J J AA 56 kohms,1/16W
RT27~30 VRS-CY1JB102J J AA 1 kohm,1/16W
OTHER CIRCUITRY PARTS
BI105 QCNWN2613AWZZ J AC Connector,Ass’y,2Pin
BI500/CNS500 QCNWN2531AWZZ J AH Connector Ass’y,12/12Pin
BI601/CNS601 QCNWN2655AWZZ J AG Connector Ass’y,5/5Pin
BI701/CNS701 QCNWN2527AWZZ J AF Connector Ass’y,6/5Pin
BI702/CNS702 QCNWN2526AWZZ J AF Connector Ass’y,6/5Pin
BI703 QCNWN2612AWZZ J AG Connector,Ass’y,5Pin
BI931/CNS931 QCNWN2528AWZZ J AK Connector Ass’y,14/13Pin
BI933/CNS933 QCNWN2530AWZZ J AF Connector Ass’y,5/4Pin
CNA100 92LCONECP53253 J AD Plug,12Pin
CNA104 92LCONE4P53253 J AB Plug,4Pin
CNP401 92LCONE3P53253 J AB Plug,3Pin
CNP501 QCNCWZX33AWZZ J Socket,33Pin
CNP502 QCNCWZX15AWZZ J AD Socket,15Pin
CNP506 QCNCWZX11AWZZ J AC Socket,11Pin
CNP531 92LCONEDP53253 J AE Plug,13Pin
CNP601 92LCONE5P53253 J AB Plug,5Pin
CNP701 QCNCWZF33AWZZ J AF Socket,33Pin
CNP702 QCNCWZF15AWZZ J AC Socket,15Pin
CNP705 92LCONE5P53253 J AB Plug,5Pin
CNP901 92LCONE5P53253 J AB Plug,5Pin
1 CNP902 QCNCM049BAWZZ J AC Plug,2Pin
CNS01 92LCONE6P53254 J AC Plug,6Pin
CNS02 92LCONE2P53254 J AB Plug,2Pin
1 F901 QFS-C402AAWNL J AD T4A L 250V
FFC701 QCNWN2523AWZZ J Flat Cable,33Pin
FFC702 QCNWN2524AWZZ J AG Flat Cable,15Pin
FFC703 QCNWN2525AWZZ J AC Flat Cable,11Pin
FL701 VVK15MS04T+-1 J AY FL Display
JK1 QJAKJ0014AWZZ J AF Jack,Headphones
JOG701 QSW-Z0016AWZZ J AF Switch,Rotary Type
[Jog Volume]
JT501 QSOCJ0410AWZZ J AF Terminal,Line1 Input/Output
JT502 QSOCJ0410AWZZ J AF Terminal,Line2/Line3 Input
LUG2~4 QLUGP0001AWZZ J AC Lug
M501(233-1) RMOTV0058AWZZ J AV Motor,Air Cooling Fan
1 PC901,902 RH-FX0008GEZZ J AE Photo-Coupler
RL897~899 RRLYD0016AWZZ J AH Relay
RX101 VHPGP513RKB-1 J AP Optical Digital In,GP513RKB
RX701 VHLGP1UM271-1 J AH Remote Sensor,GP1UM271
SO501 QSOCJ0116AWZZ J AD Jack,Subwoofer Out
SO889 QTANZ0001BGZZ J AK Terminal,Speaker
SW701 92LSWICHT1663T J AC Switch,Key Type [Digital]
SW702 92LSWICHT1663T J AC Switch,Key Type [Line]
SW703 92LSWICHT1663T J AC Switch,Key Type [Tuner (Band)]
SW704 92LSWICHT1663T J AC Switch,Key Type [Tuning Up]
SW705 92LSWICHT1663T J AC Switch,Key Type [Tuning Down]
SW706 92LSWICHT1663T J AC Switch,Key Type [Power]
TUN1 RTUNS0030AWZZ J BF Tuner Unit
1 VA901 VHVTN10V471-1 J AE
Varistor/Surge Absorber,TN10V471
CABINET PARTS
201 CCABA5075AW01 J Front Panel Ass’y
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 GCOVA1482AWSA J AC Indicator Cover,Timer LED
201- 3 HBDGB1001AWSA J AD Badge,SHARP
201- 4 HDECQ0832AWSA J AD Indicator Cover,1-Bit
201- 5 HDECQ0933AWSA J AD Indicator Cover,Remote Sensor
201- 6 HDECQ0989AWSA J AE Window,FL Display
201- 7 HDECQ0990AWSA J AG Decoration Panel,Volume Knob
201- 8 HDECQ0991AWSA J AD Decoration Panel,Function LED
201- 9 JKNBZ0940AWSA J AF Button,Function
201-10 JKNBZ0941AWSA J AE Button,Power
202 GCAB-3099AWSA J AU Top Cabinet
203 GITAR1231AWSA J AM Rear Panel
