PRICE
RANK
DESCRIPTION
NO.
PART CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
SD-AT1000H
– 7 –
CP-AT1000HF/CP-AT1000HC/CP-AT1000HR
204 JKNBZ0939AWSA J AH Knob,Volume
205 LANGK0373AWFW J AK Bracket,Front
206 LANGK0395AWFW J AC Bracket,Earth
207 LANGQ0015AWZZ J AE Bracket,1-Bit Power Conductor
208 LBSHC0002AWZZ J AD Bushing,AC Power Supply Cord
209 LCHSM0180AWFW J AQ Main Chassis
210 LHLDZ1397AWZZ J AD Holder,Delta LED
211 LHLDZ9009AWZZ J AD Holder,FL Display
212 LHLDZ9010AWZZ J AD Holder,Function LED
213 LHLDZ9012AWZZ J AD Holder,Timer LED
214 PCOVQ1010AWFW J AD Cover,Shield
215 PCOVQ1012AWSA J AE Cover,Fan Motor
216 PCUSG0022AWZZ J AB Cushion,Leg
217 PRDAR0300AWFW J AG Heat Sink,AC
218 PRDAR0278AWFW J AN Heat Sink,1-Bit Top
219 PRDAR0279AWFW J AS Heat Sink,1-Bit
220 PRDAR0283AWFW J AF Heat Sink,Main
221 PRDAR0301AWFW J AE Heat Sink,D
222 PRDAR0298AWFW J AF Heat Sink,H
223 PSHEP0140AWZZ J AE Sheet,Display PWB Protection,A
225 PSPAS0017AWZZ J AD Boss,Power PWB
226 PSPAS0019AWZZ J AC Boss,Main PWB
227 PSPAZ0039AWZZ J AC Spacer
1 228 QACCB0020AW00 J AU AC Power Supply Cord with
CNS902
1 228 QACCE0018AW00 J AL AC Power Supply Cord with
CNS902
1 228 QACCZ0029AWZZ J AC Power Supply Cord with
CNS902
1 229 QFSHD0001AWZZ J AB Holder,Fuse
230 TLABZ1371AWZZ J AC Label,Speaker
231 TSPC-1270AWZZ J AE Label,Specifications
[Except for U.K./Korea/Russia]
231 TSPC-1271AWZZ J Label,Specifications [For U.K.]
231 TSPC-1297AWZZ J Label,Specifications [For Russia]
231 TSPC-1326AWZZ J Label,Specifications [For Korea]
232 92LCSPR1431C J AA Spring,Ring
233 92LFAN5074ASY1 J AX Fan Motor Ass’y
233- 1(M501) RMOTV0058AWZZ J AV Motor,Air Cooling Fan
233- 2 LANGK0374AWFW J AE Bracket,Fan Motor
233- 3 PCUSG0095AWZZ J AD Cushion
234 92LNBAND1318A J AA Nylon Band,80mm
235 RCORF0028AWZZ J AT Core
236 ———— — Nut (Not Replacement Item)
237 RCORF0018AWZZ J AG Core
238 PSHEP0139AWZZ J AB Sheet,Display PWB Protect,B
239 PSLDM9006AWFW J AL Shield Plate,DSP
240 PCUSG0158AWZZ J AB Cushion,Shield
241 QCNWN2651AWZZ J AC Lug Wire
242 RCORF0024AWZZ J AD Core
243 LANGZ0073AWFW J Bracket,EMC
601 LX-JZ0036AWFD J AB Screw,ø3×12mm
602 LX-JZ0047AWFD J AB Screw,ø3×8mm
603 XEBSD26P10000 J AA Screw,ø2.6×10mm
604 XJBSD30P08000 J AA Screw,ø3×8mm
605 XJBSD30P12000 J AA Screw,ø3×12mm
606 XJBSD30P16000 J AA Screw,ø3×16mm
607 XJBSF30P08000 J AA Screw,ø3×8mm
608 XJBSF30P14000 J AA Screw,ø3×14mm
609 XJBSF30P16000 J AA Screw,ø3×16mm
610 LX-JZ0172AFFN J AB Screw,ø3×10mm
611 XJSSF30P10000 J AA Screw,ø3×10mm
ACCESSORIES/PACKING PARTS
1 QANTL0014AWZZ J AP AM Loop Antenna
2 QCNWG0067AWZZ J Speaker Cord
3 RRMCG0369AWSA J AU Remote Control
4 SPAKA0421AWZZ J AH Packing Add.,Left/Right
5 SPAKC1650AWZZ J Packing Case
6 SPAKP0026AWZZ J AB Polyethylene Bag,AC Power
Supply Cord [For U.K. Only]
7 SPAKZ1017AWZZ J AH Pad,Protection
8 SPAKZ1090AWZZ J AD Pad,Protection
9 SSAKA0007AWZZ J AB Polyethylene Bag,Accessories
10 SSAKH0124AWZZ J AE Polyethylene Bag,Unit
11 TCAUH0094AWZZ J AB Caution,Speaker
[Except for Korea/Russia]
11 TCAUH0096AWZZ J Caution,Speaker [For Korea]
11 TCAUH0097AWZZ J Caution,Speaker [For Russia]
12 TCAUZ0173AWZZ J AB Caution,Subwoofer
[Except for Korea/Russia]
12 TCAUZ0175AWZZ J Caution,Subwoofer [For Korea]
12 TCAUZ0176AWZZ J Caution,Subwoofer [For Russia]
13 TGAN-3170UMZZ J AE Warranty Card [For U.K. Only]
14 TINSE0543AWZZ J AD Quick Guide [For U.K.]
14 TINSZ0955AWZZ J AD Quick Guide
[Except for U.K./Korea/Russia]
14 TINSZ0970AWZZ J Quick Guide [For Russia]
14 TINSZ0971AWZZ J Quick Guide [For Korea]
15 TINSE0545AWZZ J AE Operation Manual [For U.K.]
15 TINSZ0943AWZZ J AN Operation Manual
[Except for U.K./Korea/Russia]
15 TINSZ0957AWZZ J Operation Manual [For Korea]
15 TINSZ0958AWZZ J Operation Manual [For Russia]
16 TLABE0776AWZZ J AB Label,Bar Code
[Except for Russia]
16 TLABE0792AWZZ J Label,Bar Code [For Russia]
17 TLABM0176AWSA J AC Label,Feature
18 TLABZ0604AWZZ J AB Label,Energy
[Except for Korea/Russia Only]
19 TLABZ0620AWZZ J AB Label,Saving Energy (Set)
[Except for Korea Only]
20 92LFANT1535A J AF FM Antenna
21 TLABS0102AWZZ J AB Label,Gost Rostest
[For Russia Only]
22 ———— — Battery,SUM-3
(Not Replacement Item)
[Except for U.K. Only]
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~4 92LPWB5075MANS J — Main/Display/Headphones/
Remote Sensor
(Combined Ass’y)
1 PWB-B 92LPWB5075PWRS J — Power
PWB-C 92LPWB5074PTCS J — Protect Circuit
FRONT SPEAKER BOX PARTS
901 CPNLS1084AW01 J AV Front Panel Ass’y
902 GCAB-1231AW01 J BA Rear Cabinet Ass’y
903 QTANA9017AWZZ J AK Terminal,Speaker
904 QCNWN2535AW01 J AH Speaker Cord Ass’y
905 PKYU-0008AWZZ J AD Absorber
906 TSPC-1282AWZZ J AH Label,Specifications,Right
906 TSPC-1283AWZZ J AH Label,Specifications,Left
907 XEBSF30P12000 J AA Screw,ø3×12mm
908 PCUSS0068AWZZ J AC Cushion,Speaker
SP1~4 RSPA00107AWWP J AX Speaker
CENTER SPEAKER BOX PARTS
901 CPNLS1084AW02 J AV Front Panel Ass’y
902 GCAB-1231AW01 J BA Rear Cabinet Ass’y
903 QTANA9017AWZZ J AK Terminal,Speaker
904 QCNWN2535AW01 J AH Speaker Cord Ass’y
905 PKYU-0008AWZZ J AD Absorber
906 TSPC-1286AWZZ J AH Label,Specifications
907 XEBSF30P12000 J AA Screw,ø3×12mm
908 PCUSS0068AWZZ J AC Cushion,Speaker
SP1,2 RSPA00107AWWP J AX Speaker
SURROUND SPEAKER BOX PARTS
901 CPNLS1089AW01 J AV Front Panel Ass’y
902 GCAB-1231AW01 J BA Rear Cabinet Ass’y
903 QTANA9017AWZZ J AK Terminal,Speaker
904 QCNWN2564AWZZ J AF Speaker Cord
905 PKYU-0008AWZZ J AD Absorber
906 TSPC-1284AWZZ J AH Label,Specifications,Right
906 TSPC-1285AWZZ J AH Label,Specifications,Left
907 XEBSF30P12000 J AA Screw,ø3×12mm
SP1,2 RSPA00091AW8P J AV Speaker
ACCESSORIES/PACKING PARTS
1 PCUSG0129AWSA J AC Sheet,Leg
To Next Page
