20
SJ-P43N/43N
SJ-P47N/47N
(2) Fixing of Fan motor and Fan
(2)-1 Stick U-sealer handle to Fan motor holder A.
Figure A-6
2. FAN LOUVER AND E.V COVER ASSEMBLY
Figure A-4
E.v cover sealer C
E.v cover
sealer C
Fuse ass’y
F-thermostat
E.v cover
Defrost thermo.
ass’y
E.v cover
sealer A
E.v cover
sealer G
L-band C
L-band C
Lead EV-cover
ass’y
U-sealer
handle
Fan motor
holder A
Fan clamp
Propeller fan
100
Fan motor holder B
Fan motor
Motor cushion
E.v cover
sealer B
E.v cover sealer D
E.v cover sealer E
E.v cover
AL A
E.v cover
sealer F
Fan motor holder A
U-sealer handle
U-sealer handle
7 2mm
+
+
0 1mm
C
C
SEC. C-C
E.v cover sealer C
E.v cover sealer G
E.v cover sealer A
E.v cover sealer B
E.v cover
[back side]
STICK START
STICK START
STICK START
(1)
(1)
(2)
(3)
(3)
(4)
(4)
(4)
Screw
Fan louver
Screw
Claw
Claw
Claw
Claw
2-1. How to remove the Fan louver
(1) Take out 2 screws.
(2) Insert the screwdriver into the air hole of the Fan
louver.
(3) Press the Fan louver to the left side with the
screwdriver,and pull it toward yourself to take off the
Fan louver.
2-2. E.v cover assembly
Figure A-5
Figure A-7
(1) Sticking of Sealers to E.V cover
